CHAPTER 1: Getting Started
15
Preparing the Pocket
Controller
1
Remove the card slot protector, and
then insert the supplied CF wireless
LAN card into the CF card slot.
2
Set the battery replacement switch to
the [REPLACE BATTERY] position.
3
Put the rechargeable battery into the
battery compartment.
NORMAL OPERATION
REPLACE BATTERY
Make sure that the , and marks on
the battery are aligned correctly with those
printed inside the battery compartment.
4
Set the battery replacement switch
back to the [NORMAL OPERATION]
position.
5
Remove the I/O port cover, and then
set the Pocket Controller on the
cradle.
Charging starts and the charge indicator lights
amber. When the battery is fully charged, the
indicator goes out.
I/O port cover
Charge indicator
