CHAPTER 1: Getting Started
19
Handling Floppy Disks
In order to protect data stored on floppy disks from
damage or loss, be sure to handle them with care, and
observe the following precautions.
• Do not touch the surface of the internal disk.
• Do not store or place disks near a television, radio,
loudspeaker, or any other device that generates a
magnetic field.
• Do not expose disks to extreme temperature or
humidity. The working temperature range for disks is
between 4°C and 52°C (40°F and 125°F).
• Do not use disks in a dusty, dirty, or smoky
environment.
• Remove the disk from the floppy disk drive before
turning the Disklavier off.
Write Protection
Floppy disks have a write protection tab to keep from
accidentally formatting the disk or erasing files.
Description of the Task Bar
The task bar is always displayed at the bottom of the
screen to show various information and status of the
Pocket Controller. Tapping on the icon shows the
respective setup screen, etc.
: Shows the function menus such as
[Reboot], etc.
: Shows the wireless connection status.
Blue: Excellent
Green: Good
Yellow: Average
Red: Poor
: No connection (Tap to show the detailed
Network screen.)
: Shows the volume of the Pocket Controller
itself. (Tap on it, and then move the slider
up or down to adjust the volume.)
: Tap on it, and then on [Eject card] before
you remove the CF card.
: Tap on it, and then on [Eject SD-card]
before you remove the SD card.
: Shows the battery status.
Blue: Good
Yellow: Low
Red: Very low
Green: Charging
: Shows the current time. (Tap on it to open
the [Set System Time] screen.)
Basic Precautions for Using
Floppy Disks and CDs
Protected Unprotected
The tab window is
open.
The tab window is
closed.
