CHAPTER 1: Getting Started
20
Continue to next page...
English
Loading and Ejecting a Floppy Disk
Loading
Push the disk until it clicks into place.
Ejecting
Press the eject button on the Media Center.
Note: Do not eject the floppy disk while the access
lamp is flashing or lit. Doing so can seriously damage
the disk and the floppy disk drive as well.
Handling CDs
In order to protect data stored on compact discs from
damage or loss, handle them with care, and observe the
following precautions.
• Do not touch the surface of a CD.
• Do not expose CDs to extreme temperatures or
humidity. The working temperature range is between
4°C and 52°C (40°F and 125°F).
• Wipe CDs with a clean cloth before playback.
• Remove the CD from the CD drive before turning the
Disklavier off.
Floppy disk drive on the Media Center
Eject button
Access lamp
Loading a CD
Loading
1 Press on the Media Center to open the CD
tray.
2 Place the CD on the tray, and then press to
close the tray.
CDs
The files should be formatted in ISO 9660 LEVEL1.
Floppy Disks (2DD,2HD)
• The files should be formatted in MS-DOS.
• The Disklavier reads only the files nested in the root
directory.
USB Flash Memories
The files should be formatted in FAT16 or FAT32 file
system.
USB Hard Disk Drives
The files should be formatted in FAT32 file system.
Available File Format and
Structure of Data in the
Removable Media
OPEN/
CLOSE
OPEN/
CLOSE
Labeled side
CD tray on the Media Center
