Digital Audio Inputs 269
01V—Owner’s Manual
Digital Audio Inputs
Digital Audio Outputs
Option I/O Cards
*1. De-emphasis is automatically processed when input signal contains emphasis.
*1. Channel status
Type: 2 audio channels
Category code: 2 channel PCM encoder/decoder
Copy prohibit: No
Emphasis: No
Clock accuracy: Level II (1,000 ppm)
Sampling rate: depends on internal configuration
*2. Dither: wordlength 16–24 bit
Connection Format Wordlength Level Connector
DIGITAL
STEREO IN
*1
COAXIAL IEC-60958 24 bit
0.5 V pp
(75 )
Phono
Connection Format Wordlength Level Connector
DIGITAL
STEREO OUT
COAXIAL
IEC-60958
*1
Consumer Use
24 bit
*2
0.5 V pp
(75 )
Phono
Card Format Inputs Outputs
MY8-AT
ADAT 8 IN (CH 17–24) 8 OUT (BUS, AUX, ST, CH direct)
MY8-TD
TASCAM 8 IN (CH 17–24) 8 OUT (BUS, AUX, ST, CH direct)
MY8-AE
AES/EBU 8 IN (CH 17–24) 8 OUT (BUS, AUX, ST, CH direct)
MY4-DA
Analog out 4 OUT (BUS, AUX, ST, CH direct)
MY8-AD
Analog in 8 IN (CH 17–24)
MY4-AD
Analog in 4 IN (CH 17–20)
