18
Connecting External Equipment
Connect video cameras, DVD players, and other sources to the VIDEO INPUT connectors.
* Channel 4 has a composite connector and a RGB connector, and when input is made through both at the same time, the RGB input takes priority.
fig.connect-video-source.eps
* When connection cables with resistors are used, the volume level of equipment connected to the audio inputs may be low. If this happens, use
connection cables that do not contain resistors.
Connecting Audio Players
Connect the audio output from video players, CD players, and other devices to the AUDIO INPUT connectors.
* When making the connection, be careful to connect the left and right lines correctly.
fig.connect-DVD-player.eps
Connecting Video Sources
Connecting Audio Sources
Player
Player
