Using the Play Functions
Adjusting the Overall Volume Using an Expression
Pedal
You can adjust the entire volume using an Expression Pedal. When you depress the Ex-
pression Pedal, the volume increases. The volume decreases as you tilt the pedal back.
fig.06-03
You can also specify whether the Expression Pedal will or will not control the volume during
the recording of music data (p. 81).
Likewise you can specify whether the Expression Pedal will or will not control the volume
during the playback of recorded music data (p. 81).
Adding Decay to the Sound (Damper Pedal)
When you depress the Damper (Sustain) pedal, a decay effect will be added to the voices.
While you continue depressing the damper pedal, notes will be sustained even if you re-
lease the keys.
By default the decay effect will be applied to the voices played on the Lower keyboard.
fig.06-04
You can modify the setting so that decay is only applied to notes played on the Upper keyboard (p.
92).
Decay cannot be added to the Solo voices.
Decay can not be applied to Pedal Bass voices played on the Lower keyboard (when the Pedal [To
Lower] button indicator is lit).
Decrease
the volume
Increase
the volume
NOTE
