89
Adjusting the Effects
Changing the Wall Type
By changing the type of reverb (p. 88) you can experience the
feeling of performing in various different locations, and by
changing the Wall Type (wall material) you can make further
adjustments to the way in which reverberation occurs.
1.
Press the [Utility] button.
2.
Press the Menu [ ] and [ ] buttons to
select “Wall Type.”
fig.11-04
3.
Press the Value [-] and [+] buttons to select a
Wall type.
DRAPERY
Pleated curtain
CARPET
Carpet
ACOUSTIC TILE
Acoustical tile, sound-absorptive
tile
WOOD
Wood
BRICK
Brick
PLASTER
Plaster
CONCRETE BLOCK
Concrete block
MARBLE
Marble
To return to the basic screen, press the [Utility] or [Dis-
play/Exit] button.
Sustain Effect
Sustain allows you to add a Sustain effect or decay to each
voice after the keys are released.
1.
Press the [Utility] button.
2.
Press the Menu [ ] and [ ] buttons to
select “Sustain.”
3.
Press the Part [ ] and [ ] buttons to select
the part whose sustain you wish to adjust.
Keyboard
Upper, Lower, Pedal
4.
Press the Value [-] and [+] buttons to adjust the
setting.
ON
The Sustain effect is applied to the voices
OFF
The Sustain effect is not applied to the voices
To return to the basic screen, press the [Utility] or [Dis-
play/Exit] button.
Changing the Sustain Length
The sustain length can be set independently (SHORT,
MIDDLE (Medium) or LONG) for the Upper and Lower
keyboards and Bass Pedalboard. You can make a separate
setting for each keyboard.
1.
Press the [Utility] button.
2.
Press the Menu [ ] and [ ] buttons to
select “Sustain Length.”
fig.11-06
3.
Press the Part [ ] and [ ] buttons to select
the part whose sustain length you wish to adjust.
Keyboard
Upper, Lower, Pedal
4.
Press the Value [-] and [+] buttons to adjust the
setting.
Settings
SHORT, MIDDLE, LONG
To return to the basic screen, press the [Utility] or [Dis-
play/Exit] button.
