97
Various Other Settings
Specifying Transmission of PC
Numbers (Send PC Switch)
Transmission of PC (Program Change) numbers can be
switched ON/OFF.
1.
Press the [Utility] button.
2.
Press the Menu [ ] and [ ] buttons to
select “Send PC Switch.”
fig.12-25
3.
Press the Value [-] and [+] buttons to switch the
PC Switch “ON” or “OFF.”
ON
PC numbers are transmitted
OFF
PC numbers are not transmitted
To return to the basic screen, press the [Utility] or [Dis-
play/Exit] button.
➔
This setting remains stored in memory even while power is
turned off.
Setting PC Numbers (PC
Number)
You can specify the Program Change number that will be
transmitted from MIDI Out when a Registration is selected.
1.
Press the [Utility] button.
2.
Press the Menu [ ] and [ ] buttons to
select “PC Number.”
fig.12-26
3.
Press the Part [ ] and [ ] buttons to select
“Bank MSB,” ”Bank LSB,” ”PC Num.”
4.
Press the Value [-] and [+] buttons to change
the setting.
Setting
Bank MSB (Bank Select MSB) 0-127
Bank LSB (Bank Select LSB) 0-127
PC Num (PC Number) 1-128
To return to the basic screen, press the [Utility] or [Dis-
play/Exit] button.
