dB
Value
X6#
dB
Value
X6#
dB
Value
X6#
dB
Value
X6#
dB
Value
X6#
dB
Value
X6#
dB
Value
X6#
dB
Value
X6#
dB
Value
X6#
dB
Value
X6#
-100.0 1048
-99.9 1049 -99.8 1050 -99.7 1051 -99.6 1052 -99.5 1053 -99.4 1054 -99.3 1055 -99.2 1056 -99.1 1057 -99.0 1058
-98.9 1059 -98.8 1060 -98.7 1061 -98.6 1062 -98.5 1063 -98.4 1064 -98.3 1065 -98.2 1066 -98.1 1067 -98.0 1068
-97.9 1069 -97.8 1070 -97.7 1071 -97.6 1072 -97.5 1073 -97.4 1074 -97.3 1075 -97.2 1076 -97.1 1077 -97.0 1078
-96.9 1079 -96.8 1080 -96.7 1081 -96.6 1082 -96.5 1083 -96.4 1084 -96.3 1085 -96.2 1086 -96.1 1087 -96.0 1088
-95.9 1089 -95.8 1090 -95.7 1091 -95.6 1092 -95.5 1093 -95.4 1094 -95.3 1095 -95.2 1096 -95.1 1097 -95.0 1098
-94.9 1099 -94.8 1100 -94.7 1101 -94.6 1102 -94.5 1103 -94.4 1104 -94.3 1105 -94.2 1106 -94.1 1107 -94.0 1108
-93.9 1109 -93.8 1110 -93.7 1111 -93.6 1112 -93.5 1113 -93.4 1114 -93.3 1115 -93.2 1116 -93.1 1117 -93.0 1118
-92.9 1119 -92.8 1120 -92.7 1121 -92.6 1122 -92.5 1123 -92.4 1124 -92.3 1125 -92.2 1126 -92.1 1127 -92.0 1128
-91.9 1129 -91.8 1130 -91.7 1131 -91.6 1132 -91.5 1133 -91.4 1134 -91.3 1135 -91.2 1136 -91.1 1137 -91.0 1138
-90.9 1139 -90.8 1140 -90.7 1141 -90.6 1142 -90.5 1143 -90.4 1144 -90.3 1145 -90.2 1146 -90.1 1147 -90.0 1148
-89.9 1149 -89.8 1150 -89.7 1151 -89.6 1152 -89.5 1153 -89.4 1154 -89.3 1155 -89.2 1156 -89.1 1157 -89.0 1158
-88.9 1159 -88.8 1160 -88.7 1161 -88.6 1162 -88.5 1163 -88.4 1164 -88.3 1165 -88.2 1166 -88.1 1167 -88.0 1168
-87.9 1169 -87.8 1170 -87.7 1171 -87.6 1172 -87.5 1173 -87.4 1174 -87.3 1175 -87.2 1176 -87.1 1177 -87.0 1178
-86.9 1179 -86.8 1180 -86.7 1181 -86.6 1182 -86.5 1183 -86.4 1184 -86.3 1185 -86.2 1186 -86.1 1187 -86.0 1188
-85.9 1189 -85.8 1190 -85.7 1191 -85.6 1192 -85.5 1193 -85.4 1194 -85.3 1195 -85.2 1196 -85.1 1197 -85.0 1198
-84.9 1199 -84.8 1200 -84.7 1201 -84.6 1202 -84.5 1203 -84.4 1204 -84.3 1205 -84.2 1206 -84.1 1207 -84.0 1208
-83.9 1209 -83.8 1210 -83.7 1211 -83.6 1212 -83.5 1213 -83.4 1214 -83.3 1215 -83.2 1216 -83.1 1217 -83.0 1218
-82.9 1219 -82.8 1220 -82.7 1221 -82.6 1222 -82.5 1223 -82.4 1224 -82.3 1225 -82.2 1226 -82.1 1227 -82.0 1228
-81.9 1229 -81.8 1230 -81.7 1231 -81.6 1232 -81.5 1233 -81.4 1234 -81.3 1235 -81.2 1236 -81.1 1237 -81.0 1238
-80.9 1239 -80.8 1240 -80.7 1241 -80.6 1242 -80.5 1243 -80.4 1244 -80.3 1245 -80.2 1246 -80.1 1247 -80.0 1248
-79.9 1249 -79.8 1250 -79.7 1251 -79.6 1252 -79.5 1253 -79.4 1254 -79.3 1255 -79.2 1256 -79.1 1257 -79.0 1258
-78.9 1259 -78.8 1260 -78.7 1261 -78.6 1262 -78.5 1263 -78.4 1264 -78.3 1265 -78.2 1266 -78.1 1267 -78.0 1268
-77.9 1269 -77.8 1270 -77.7 1271 -77.6 1272 -77.5 1273 -77.4 1274 -77.3 1275 -77.2 1276 -77.1 1277 -77.0 1278
-76.9 1279 -76.8 1280 -76.7 1281 -76.6 1282 -76.5 1283 -76.4 1284 -76.3 1285 -76.2 1286 -76.1 1287 -76.0 1288
-75.9 1289 -75.8 1290 -75.7 1291 -75.6 1292 -75.5 1293 -75.4 1294 -75.3 1295 -75.2 1296 -75.1 1297 -75.0 1298
-74.9 1299 -74.8 1300 -74.7 1301 -74.6 1302 -74.5 1303 -74.4 1304 -74.3 1305 -74.2 1306 -74.1 1307 -74.0 1308
-73.9 1309 -73.8 1310 -73.7 1311 -73.6 1312 -73.5 1313 -73.4 1314 -73.3 1315 -73.2 1316 -73.1 1317
-73.0 1318
-72.9 1319 -72.8 1320 -72.7 1321 -72.6 1322 -72.5 1323 -72.4 1324 -72.3 1325 -72.2 1326 -72.1 1327
-72.0 1328
-71.9 1329 -71.8 1330 -71.7 1331 -71.6 1332 -71.5 1333 -71.4 1334 -71.3 1335 -71.2 1336 -71.1 1337 -71.0 1338
X6#
— Pre-mixer gain (
b
), Virtual return gain (
f
), and output volume (
e
)
NOTE: Pre-mixer gain (
b
) and virtual return gain (
f
) range; –100.0dB to +12.0dB.
Output volume (
e
) range; –100.0dB to 0.0dB.
Table 6.
X6#
— Pre-mixer, Virtual Return, and Output Level Control
DMP64 • SIS Programming and Control 116
