108
Effect/Parameter List
Appendices
Balance (Effect Balance) #
Adjust the volume balance between the direct sound and the
chorus sound. With a setting of D100:0W only the direct sound
will be output, and with a setting of D0:100W only the chorus
sound will be output.
Level (Output Level)
Adjust the output level.
15: ST.FLANGER (Stereo Flanger)
This is a stereo flanger. (The LFO has the same phase for left
and right.) It produces a metallic resonance that rises and falls
like a jet airplane taking off or landing. A filter is provided so
that you can adjust the timbre of the flanged sound.
Pre Delay (Pre Delay Time)
Adjust the time delay from when the direct sound begins until
the flanger sound is heard.
Rate #
Adjust the rate of modulation.
Depth
Adjust the depth of modulation.
Feedback (Feedback Level) #
Adjust the proportion (%) of the processed sound that is
returned (fed back) into the input. Positive (+) settings will
return the sound in phase, and negative (-) settings will return
the sound in reverse phase.
The effect becomes more prominent as the value is increased.
Phase
Adjust the spatial spread of the sound.
Filter (Filter Type)
Select the type of filter.
OFF
: a filter will not be used
LPF
: cut the frequency range above the cutoff frequency
HPF
: cut the frequency range below the cutoff frequency
Cutoff (Cutoff Frequency)
Adjust the basic frequency of the filter.
Low Gain
Adjust the gain of the low frequency range.
Positive (+) settings will emphasize (boost) the low frequency
range.
High Gain
Adjust the gain of the high frequency range.
Positive (+) settings will emphasize (boost) the high frequency
range.
Balance (Effect Balance)
Adjust the volume balance between the direct sound and the
flanger sound. With a setting of D100:0W only the direct sound
will be output, and with a setting of D0:100W only the flanger
sound will be output.
Level (Output Level)
Adjust the output level.
16: STEP FLANGER
The Step Flanger effect is a flanger in which the flanger pitch
changes in steps.
Pre Delay (Pre Delay Time)
Adjust the time delay from when the direct sound begins until
the flanger sound is heard.
Rate
Adjust the rate of modulation.
Depth
Adjust the depth of modulation.
Feedback (Feedback Level) #
Adjust the proportion (%) of the flanger sound that is returned
(fed back) into the input. Negative (-) settings will invert the
phase.
The effect becomes more prominent as the value is increased.
Phase
Adjust the spatial spread of the sound.
Step Rate #
Adjust the rate (period) of pitch change.
➔
Step Rate parameter can be set as a note-value of a tempo. In
this case, specify the value of the desired note.
Low Gain
Adjust the gain of the low frequency range.
Positive (+) settings will emphasize (boost) the low frequency
range.
High Gain
Adjust the gain of the high frequency range.
Positive (+) settings will emphasize (boost) the high frequency
range.
Balance (Effect Balance)
Adjust the volume balance between the direct sound and the
flanger sound. With a setting of D100:0W only the direct sound
will be output, and with a setting of D0:100W only the chorus
sound will be output.
Level (Output Level)
Adjust the output level.
17: STEREO DELAY
Delay L (Delay Time Left)
Adjust the time from the direct sound until when the left delay
sound is heard.
Delay R (Delay Time Right)
Adjust the time from the direct sound until when the right
delay sound is heard.
Feedback (Feedback Level) #
Adjust the proportion (%) of the delay sound that is fed back
into the effect. Negative (-) settings will invert the phase.
