80
Detailed Settings for Each Function ([EDIT])
Edit Mode
Selecting the Part to Be Set
(<Part>, Tone)
Choose the Part for which you want to make settings.
Setting the Reverb/Chorus Depth
(Reverb/Chorus Amount)
This sets the depth of the reverb and chorus effects.
NOTE
When this value is set to “0,” no reverb or chorus effect is
applied when the REVERB or CHORUS knob is turned.
How to apply the Reverb/Chorus Amount
The manner in which the effect is applied will differ
depending on the settings for MFX Source and MFX Dest (p.
77).
- When MFX Dest is set to ALL PART
The Reverb/Chorus Amount setting for the part selected
for MFX Source applies to all parts. However, when the
MFX Source is set to FIXED, the Reverb/Chorus Amount
setting for UPPER 1 applies to all parts.
- When MFX Dest is set to SAME MFX
The Reverb/Chorus Amount setting for the part selected
for MFX Source applies to parts assigned the same MFX
Type as the part selected for MFX Source.
Changing the Effect Applied to
the Tone (MFX)
This sets the multi-effect applied to the tone.
NOTE
The MFX selected here may not be applied with certain MFX
Source and MFX Dest settings.
For details, refer to
“MFX Source, MFX Dest”
(p. 77).
Playing Sound Monophonically
(Mono/Poly)
Specifies whether the tone will play polyphonically (POLY)
or monophonically (MONO).
The MONO setting is effective when playing a solo
instrument tone such as sax or flute.
Additionally, when this is set to MONO/LEGATO, you can
have monophonic performances played legato. Legato is a
playing style in which the spaces between notes are
smoothed, creating a flowing feel with no borders between
the notes. This creates a smooth transition between notes,
which is effective when you wish to simulate the
hammering-on and pulling-off techniques used by a
guitarist.
Changing the Pitch
(Coarse/Fine Tune)
This sets the pitch of the tone.
1 cent = 1/100 semitone
NOTE
With some Tones, there may be ranges in which the pitch does
not change as intended.
Parameter Value
<Part>
1–16
Parts assigned to the Local
parts are indicated by a
marker (UPPER1) appear-
ing after the part name.
Tone
When the part to be set is
selected, the name of the as-
signed tone appears.
You can select tone using
the TONE SELECT buttons.
Parameter
Value
Reverb Amount
0–127
Chorus Amount 0–127
Parameter
Value
MFX
Refer to the
“Effect/Parameter List”
(p. 104).
Parameter
Value Description
Mono/Poly
MONO
Only the last-played note
will sound.
POLY
Two or more notes can be
played simultaneously.
MONO/
LEGATO
Legato is applied to mono-
phonic performances.
Parameter
Value Description
Coarse Tune
-48– +48
(+/- 4 octaves)
Sets the sound’s pitch
in semitone units.
Fine Tune
-50– +50
(+/- 50 cents)
Sets the sound’s pitch
in units of one cent.
