111
Effect/Parameter List
Appendices
Level (Output Level)
Adjust the output level.
22: 2V PCH SHIFT (2 Voice Pitch Shifter)
A Pitch Shifter shifts the pitch of the direct sound. This 2-voice
pitch shifter has two pitch shifters, and can add two pitch
shifted sounds to the direct sound.
Coarse A (Coarse Pitch A) #1
Adjust the pitch of Pitch Shift A in semitone steps (-2–+1
octaves).
Fine A (Fine Pitch A) #1
Make fine adjustments to the pitch of Pitch Shift A in 2-cent
steps (-100–+100 cents).
One cent is 1/100th of a semitone.
Pan A (Output Pan A)
Adjust the stereo location of the Pitch Shift A sound. L64 is far
left, 0 is center, and 63R is far right.
PreDelayA (Pre Delay Time A)
Adjust the time delay from when the direct sound begins until
the Pitch Shift A sound is heard.
Coarse B (Coarse Pitch B) #2
Adjust the pitch of Pitch Shift B in semitone steps (-2–+1
octaves).
Fine B (Fine Pitch B) #2
Make fine adjustments to the pitch of Pitch Shift B in 2-cent
steps (-100–+100 cents).
One cent is 1/100th of a semitone.
Pan B (Output Pan B)
Adjust the stereo location of the Pitch Shift B sound. L64 is far
left, 0 is center, and 63R is far right.
PreDelayB (Pre Delay Time B)
Adjust the time delay from when the direct sound begins until
the Pitch Shift A sound is heard.
Mode (Pitch Shifter Mode)
Higher settings of this parameter will result in slower response,
but steadier pitch.
Level Bal (Level Balance)
Adjust the volume balance between the Pitch Shift A and Pitch
Shift B sounds.
When set to A100:0B, only the sound of Pitch Shift A is output;
when set to A0:100B, only the sound of Pitch Shift B is output.
Balance (Effect Balance)
Adjust the volume balance between the direct sound and the
pitch shift sound. With a setting of D100:0W only the direct
sound will be output, and with a setting of D0:100W only the
pitch shift sound will be output.
Level (Output Level)
Adjust the output level.
23: FBK PCH SHIFT (Feedback Pitch Shifter)
This pitch shifter allows the pitch shifted sound to be fed back
into the effect.
Coarse (Coarse Pitch) #1
Adjust the pitch of the pitch shifted sound in semitone steps (-
2–+1 octaves).
Fine (Fine Pitch) #1
Make fine adjustments to the pitch of the pitch shifted sound in
2-cent steps (one cent is 1/100th of a semi tone).
Feedback (Feedback Level) #
Adjust the proportion (%) of the processed sound that is fed
back into the effect. Negative (-) settings will invert the phase.
Pre Delay (Pre Delay Time)
Adjust the time delay from when the direct sound begins until
the pitch shifted sound is heard.
Mode (Pitch Shifter Mode)
Higher settings of this parameter will result in slower response,
but steadier pitch.
Pan (Output Pan)
Adjust the stereo location of the pitch shifted sound. L64 is far
left, 0 is center, and 63R is far right.
Low Gain
Adjust the gain of the low frequency range.
Positive (+) settings will emphasize (boost) the low frequency
range.
High Gain
Adjust the gain of the high frequency range.
Positive (+) settings will emphasize (boost) the high frequency
range.
Balance (Effect Balance)
Adjust the volume balance between the direct sound and the
pitch shift sound. With a setting of D100:0W only the direct
sound will be output, and with a setting of D0:100W only the
pitch shift sound will be output.
Level (Output Level)
Adjust the output level.
24: REVERB
The Reverb effect adds reverberation to the sound, simulating
an acoustic space.
Type (Reverb Type)
Select the type of Reverb effect.
ROOM1
: dense reverb with short decay
ROOM2
: sparse reverb with short decay
STAGE1
: reverb with greater late reverberation
STAGE2
: reverb with strong early reflections
HALL1
: reverb with clear reverberance
HALL2
: reverb with rich reverberance
Pre Delay (Pre Delay Time)
Adjust the time delay from when the direct sound begins until
the reverb sound is heard.
