Effect/Parameter List
Appendices
Effects Parameter List
➔
“Making Multi-Effects Settings”
(p. 77)
Multi-effects Types are indicated in bold characters.
“Parameter” refers to the parameter assigned to <Other Prm> in
MFX Control.
“Value” refers to the values that can be set using the
[CONTROL] knobs or in Value.
01: STEREO EQ
Parameter Value
Low Freq Low frequency 200, 400 Hz
Low Gain Low gain -15– +15 dB
High Freq High frequency 2000, 4000, 8000 Hz
High Gain High gain -15– +15 dB
Mid1 Freq Middle 1 frequency 200–8000Hz (*1)
Mid1 Q Middle 1 Q 0.5, 1.0, 2.0, 4.0, 8.0
Mid1 Gain Middle 1 gain -15– +15 dB
Mid2 Freq Middle 2 frequency 200-8000 Hz (*1)
Mid2 Q Middle 2 Q 0.5, 1.0, 2.0, 4.0, 8.0
Mid2 Gain Middle 2 gain -15– +15 dB
Level Output level 0–127
*1: 200, 250, 315, 400, 500, 630, 800, 1000, 1250, 1600, 2000, 2500, 3150,
4000, 5000, 6300, 8000 Hz
02: OVERDRIVE
Parameter Value
Drive Drive 0–127
Level Output level 0–127
Low Gain Low gain -15– +15 dB
High Gain High gain -15– +15 dB
Amp Type Amp simulator type SMALL, BUILT-IN,
2-STACK, 3-STACK
Pan Output pan L64–0–63R
03: DISTORTION
Parameter Value
Drive Drive 0–127
Level Output level 0–127
Low Gain Low gain -15– +15 dB
High Gain High gain -15– +15 dB
Amp Type Amp simulator type SMALL, BUILT-IN,
2-STACK, 3-STACK
Pan Output pan L64–0–63R
04: PHASER
Parameter Value
Manual Manual 100–8000 Hz
Rate Rate 0.05–10.00 Hz
Depth Depth 0–127
Resonance Resonance 0–127
Mix Mix level 0–127
Pan Output pan L64–0–63R
Level Output level 0–127
05: SPECTRUM
Parameter Value
Band 1 Band 1 gain -15– +15 dB
Band 2 Band 2 gain -15– +15 dB
Band 3 Band 3 gain -15– +15 dB
Band 4 Band 4 gain -15– +15 dB
Band 5 Band 5 gain -15– +15 dB
Band 6 Band 6 gain -15– +15 dB
Band 7 Band 7 gain -15– +15 dB
Band 8 Band 8 gain -15– +15 dB
QQ 0.5, 1.0, 2.0, 4.0, 8.0
Pan Output pan L64–0–63R
Level Output level 0–127
06: ENHANCER
Parameter Value
Sens Sensitivity 0–127
Mix Mix level 0–127
Low Gain Low gain -15– +15 dB
High Gain High gain -15– +15 dB
Level Output level 0–127
07: AUTO WAH
Parameter Value
Filter Filter type LPF, BPF
Sens Sensitivity 0–127
Manual Manual 0–127
Peak Peak 0–127
Rate Rate 0.05–10.00 Hz
Depth Depth 0–127
Level Output level 0–127
08: ROTARY
Parameter Value
Low Slow Low frequency slow rate 0.05–10.00 Hz
Low Fast Low frequency fast rate 0.05–10.00 Hz
Low Accel Low frequency acceleration 0–15
Low Level Low frequency level 0–127
Hi Slow High frequency slow rate 0.05–10.00 Hz
Hi Fast High frequency fast rate 0.05–10.00 Hz
Hi Accel High frequency acceleration 0–15
Hi Level High frequency level 0–127
Separate Separation 0–127
Speed Speed SLOW, FAST
Level Output level 0–127
09: COMPRESSOR
Parameter Value
Attack Attack time 0–127
Sustain Sustain 0–127
Post Gain Post gain 0, +6, +12, +18 dB
Low Gain Low gain -15– +15 dB
High Gain High gain -15– +15 dB
Pan Output pan L64–0–63R
Level Output level 0–127
