120
Effect/Parameter List
Appendices
PreFilter (Pre Filter Type)
Adjust the type of filter that will be applied before the sound
passes through the Lo-Fi effect.
PostFilter1 (Post Filter 1 Type)
Adjust the type of filter that will be applied after the sound
passes through the Lo-Fi effect.
Post Fltr2 (Post Filter 2 Type)
OFF
: A post filter 2 will not be used.
LPF
: The frequency region above the Frequency (Cutoff
Frequency) setting will be cut.
HPF
: The frequency region below the Frequency (Cutoff
Frequency) setting will be cut.
Frequency (Cutoff Frequency)
Sets the cutoff frequency when a specific frequency band is cut
off by a filter.
Low Gain
Adjust the low frequency gain (amount of boost or cut).
Positive (+) settings will emphasize (boost) the low frequency
range.
High Gain
Adjust the high frequency gain (amount of boost or cut).
Positive (+) settings will emphasize (boost) the high frequency
range.
Balance (Effect Balance) #
Sets the volume balance between the direct sound and the effect
sound.
With a setting of D100:0W only the direct sound will be output,
and with a setting of D0:100W only the effect sound will be
output.
Pan (Output Pan)
Adjust the stereo location of the output sound. A setting of L64
is far left, 0 is center, and 63R is far right.
Level (Output Level)
Adjust the output level.
51: LOFI NOISE
In addition to a Lo-Fi effect, this effect also generates various
types of noise, such as radio noise and disc noise.
Type (LoFi Type)
Lowers the audio quality. The audio quality will worsen as this
setting is increased.
PstFilter (Post Filter Type)
OFF
: A filter will not be used.
LPF
: The frequency region above the Frequency (Cutoff
Frequency) setting will be cut.
HPF
: The frequency region below the Frequency (Cutoff
Frequency) setting will be cut.
Frequency (Cutoff Frequency)
Sets the cutoff frequency when a specific frequency band is cut
off by a filter.
Radio Dtn (Radio Detune) #
Simulates the tuning noise of a radio. As this value is raised, the
tuning will drift further.
Noise Lvl (Noise Level)
Adjust the volume of the radio noise.
Disc Type (Disc Noise Type)
Selects the type of record noise. The frequency at which the
noise is heard will depend on the selected type.
Disc LPF (Disc Low Pass Filter)
Adjust the cutoff frequency of the low pass filter that is applied
to the record noise.
Disc Lvl (Disc Noise Level)
Adjust the volume of the record noise.
Low Gain
Adjust the low frequency gain (amount of boost or cut).
Positive (+) settings will emphasize (boost) the low frequency
range.
High Gain
Adjust the high frequency gain (amount of boost or cut).
Positive (+) settings will emphasize (boost) the high frequency
range.
Balance (Effect Balance) #
Sets the volume balance between the direct sound and the effect
sound.
With a setting of D100:0W only the direct sound will be output,
and with a setting of D0:100W only the effect sound will be
output.
Pan (Output Pan)
Adjust the stereo position of the delay sound. A setting of L64 is
far left, 0 is center, and 63R is far right.
Level (Output Level)
Adjust the output level.
52: SP SIMULATOR (Speaker Simulator)
Speaker Simulator is an effect that simulates the speaker type
and mic settings used to record the speaker sound.
Sp Type (Speaker Type)
Select the type of speaker. The specifications of each type are as
follows. The speaker column indicates the diameter of each
speaker unit (in inches) and the number of units.
Type Cabinet Speaker Microphone
SMALL 1 small open-back enclosure 10 dynamic mic
SMALL 2 small open-back enclosure 10 dynamic mic
MIDDLE open back enclosure 12 x 1 dynamic mic
JC-120 open back enclosure 12 x 2 dynamic mic
BUILT IN 1 open back enclosure 12 x 2 dynamic mic
BUILT IN 2 open back enclosure 12 x 2 condenser mic
BUILT IN 3 open back enclosure 12 x 2 condenser mic
BUILT IN 4 open back enclosure 12 x 2 condenser mic
BUILT IN 5 open back enclosure 12 x 2 condenser mic
BG STACK 1 sealed enclosure 12 x 4 condenser mic
BG STACK 2 large sealed enclosure 12 x 4 condenser mic
MS STACK 1 large sealed enclosure 12 x 4 condenser mic
MS STACK 2 large sealed enclosure 12 x 4 condenser mic
METAL STACK large double stack 12 x 4 condenser mic
2-STACK large sealed enclosure 12 x 4 condenser mic
3-STACK large sealed enclosure 12 x 4 condenser mic
