MIDI Implementation
Model: VR-760 (Performance Keyboard)
Date: Nov. 1, 2002
Version: 1.00
1. Receive data
■Channel Voice Messages
●Note off
Status 2nd byte 3rd byte
8nH kkH vvH
9nH kkH 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
kk = note number: 00H - 7FH (0 - 127)
vv = note off velocity: 00H - 7FH (0 - 127)
* Some instruments are not received in Rhythm set.
●Note on
Status 2nd byte 3rd byte
9nH kkH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
kk = note number: 00H - 7FH (0 - 127)
vv = note on velocity: 01H - 7FH (1 - 127)
* Not received by the Organ Part.
●Control Change
❍Bank Select (Controller number 0, 32)
Status 2nd byte 3rd byte
BnH 00H mmH
BnH 20H llH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm, ll = Bank number: 00 00H - 7F 7FH (bank.1 - bank.16384)
* The Registration, Rhythms, and Tones corresponding to each Bank Select are as follows.
* The SRX series corresponding to each Bank Select are to see the SRX series owner’s
manual.
+————————————————————————————————————————————————————————————————+
| BANK SELECT | PROGRAM | GROUP | NUMBER |
| MSB | LSB | NUMBER | | |
|—————+———————————+———————————+——————————————————————+———————————|
| 085 | 000 | 001 — 064 | Registration | 001 — 064 |
| | 064 | 001 — 003 | One Touch Regist. | 001 — 003 |
| 086 | 064 | 001 — 004 | Rhythm Set | 001 — 004 |
| 087 | 064 | 001 — 009 | Tone (Piano) | 001 — 009 |
| | 065 | 001 — 018 | Tone (Synth) | 001 — 018 |
| | 066 | 001 — 018 | Tone (Synth Timbre) | 001 — 018 |
| 092 | 000 — | 001 — | SRX Rhythm | 001 — |
| | : | | : | |
| 093 | 000 — | 001 — | SRX Patch | 001 — |
| | : | | : | |
+————————————————————————————————————————————————————————————————+
❍Modulation (Controller number 1)
Status 2nd byte 3rd byte
BnH 01H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Modulation depth: 00H - 7FH (0 - 127)
* Not received by the Organ Part.
❍Portamento Time (Controller number 5)
Status 2nd byte 3rd byte
BnH 05H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Portamento Time: 00H - 7FH (0 - 127)
* Not received by the Organ Part.
❍Data Entry (Controller number 6, 38)
Status 2nd byte 3rd byte
BnH 06H mmH
BnH 26H llH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm, ll = the value of the parameter specified by RPN/NRPN
mm = MSB, ll = LSB
* Not received by the Organ Part.
❍Volume (Controller number 7)
Status 2nd byte 3rd byte
BnH 07H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Volume: 00H - 7FH (0 - 127)
❍Panpot (Controller number 10)
Status 2nd byte 3rd byte
BnH 0AH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Panpot: 00H - 40H - 7FH (Left - Center - Right)
*Not received by the Organ Part.
❍Expression (Controller number 11)
Status 2nd byte 3rd byte
BnH 0BH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Expression: 00H - 7FH (0 - 127)
*Not received by the Piano Part when the Piano Exp Sw
(EDIT: System Basic: Piano Exp Sw) is OFF.
❍General Purpose Controller 1 (Controller number 16)
Status 2nd byte 3rd byte
BnH 10H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
* Depending on the Control Message settings (Edit: System MIDI: Control Message).
❍General Purpose Controller 2 (Controller number 17)
Status 2nd byte 3rd byte
BnH 11H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
* Depending on the Control Message settings (Edit: System MIDI: Control Message).
❍General Purpose Controller 3 (Controller number 18)
Status 2nd byte 3rd byte
BnH 12H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
* Depending on the Control Message settings (Edit: System MIDI: Control Message).
❍General Purpose Controller 4 (Controller number 19)
Status 2nd byte 3rd byte
BnH 13H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
* Depending on the Control Message settings (Edit: System MIDI: Control Message).
❍Hold 1 (Controller number 64)
Status 2nd byte 3rd byte
BnH 40H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
*Not received by the Organ Part when the Organ Damper SW
(EDIT: System Basic: Organ Damper SW) is OFF.
❍Portamento (Controller number 65)
Status 2nd byte 3rd byte
BnH 41H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
*Not received by the Organ Part.
❍Sostenuto (Controller number 66)
Status 2nd byte 3rd byte
BnH 42H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
*Not received by the Organ Part.
