Detailed Settings for Each Function (EDIT)
EDIT
Piano Settings for
Registrations
(REGISTRATION PIANO)
Piano Volume (0–127)
This changes the volume level of the piano part. This setting
performs the same function as the panel [PIANO VOLUME]
knob.
Piano Oct Shift (-2–+2)
This changes the pitch of the piano part in octave units.
Piano Fine Tune (-50–+50)
This adjusts the pitch of the piano part in cent (1/100
semitone) units.
Changing the Stereo Piano Breadth
Stereo Width (0–63)
This sets the lateral breadth of the piano part sound. The area
in which the sound is played widens as the value is
increased.
This changes the way acoustic piano and other stereo
sampled sounds are spread out. Even with electric piano
sounds, this changes the way the stereo tremolo and chorus
sounds spread out.
Fine Tuning the Sonorities of Piano
Chords
Stretch Tune (OFF/1/2/3)
This determines the pitch settings for a special tuning
method for the piano that raises the upper registers even
higher, while pulling the lower registers even lower (stretch
tuning). Setting this to Off gives the VR-760 equal
temperament, while setting a value of 3 stretches the change
in pitch in the high and low registers to the maximum
degree.
Adjusting the Piano Attenuation
This sets the decay and release times for the piano part.
Decay Time (-64–+63)
This adjusts the rate at which the sound is attenuated while
the keys are being pressed. The attenuation is lengthened as
the value is raised in the positive direction, while negative
values hasten the attenuation.
Release Time (-64–+63)
This adjusts the time it takes for the sounds to stop after the
keys are released. The reverberation lengthens the sound
more as the value is raised in the positive direction, while
negative values give the sound more crispness.
Changing the Function of the Mic/Amp
Mic/Amp SW (MIC SIM/AMP SIM)
This changes the function of the MIC/AMP section on the
panel.
Settings Multi-Effect of Piano Part
The piano multi-effects includes chorus, tremolo, wah, and
phaser effects processors, and with the factory settings,
DEPTH and RATE are enabled as parameters for these
effects. Using these parameters allows you make even more
detailed settings to the effects.
Chorus Return Level (0–127)
This sets the volume level of the effect signal that is returned
when the MFX chorus is selected.
Tremolo Type (MONO/STEREO)
This enables you to select the way the tremolo behaves when
tremolo is selected as the MFX.
Wah Type (MOD/TOUCH)
This enables you to select the way the wah behaves when
wah is selected as the MFX.
When SYSTEM BASIC Control Pedal Assign (Ctrl Pdl
Assign) is set to PIANO PEDAL WAH, you can also have
this function as a pedal wah. Pedal wah is a function that
changes the tone in response to how far the external pedal is
depressed.
• When Wah Type is set to TOUCH, the panel [RATE] knob
functions as a Touch Wah Sens (sensitivity setting that
determines the point at which the touch wah starts to
function).
• When PIANO PEDAL WAH is set as the SYSTEM BASIC
Control Pedal Assign (Ctrl Pdl Assign) value, the pedal
value is given priority. Furthermore, the panel [RATE]
knobs do not function at this time.
Value Explanation
MIC SIM Selects the Mic Simulation function. This is
effective with acoustic sounds.
AMP SIM Selects the Amp Simulation function. This is
effective with electric sounds.
Value Explanation
MONO The volume changes cyclically. This is effective
when the VR-760 is being used in mono.
STEREO The volume level is cyclically distributed to the
left and right sides. This is effective when the
VR-760 is being used in stereo.
Value Explanation
MOD This changes the tone cyclically.
TOUCH The tone changes in response to the force with
which the keys are played.
