MIDI Implementation
Appendices
❍Soft (Controller number 67)
Status 2nd byte 3rd byte
BnH 43H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
* Only received by the Piano Part.
❍Resonance (Controller number 71)
Status 2nd byte 3rd byte
BnH 47H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv= Resonance value (relative change): 00H - 7FH (-64 - 0 - +63)
* Not received by the Organ Part.
Release Time (Controller number 72)
Status 2nd byte 3rd byte
BnH 48H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Release Time value (relative change): 00H - 7FH (-64 - 0 - +63)
* Not received by the Organ Part.
❍Attack time (Controller number 73)
Status 2nd byte 3rd byte
BnH 49H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Attack time value (relative change): 00H - 7FH (-64 - 0 - +63)
* Not received by the Organ Part.
❍Cutoff (Controller number 74)
Status 2nd byte 3rd byte
BnH 4AH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Cutoff value (relative change): 00H - 7FH (-64 - 0 - +63)
* Not received by the Organ Part.
❍Sound Controller 1-9 (Controller number 70-78)
Status 2nd byte 3rd byte
BnH ccH vvH
n = MIDI channel number : 0H - FH (ch.1 - ch.16)
cc = control change number : 46H - 4EH (70-78)
vv = control value : 00H - 7FH (0 - 127) 0-63 = OFF,64-127 = ON
* Receives harmonic var value.
* Received by the Organ Part.
* Not received when MIDI SOUND CONTROLERS SWITCH
(Edit: System MIDI: MIDI Snd Ctrl) is OFF.
cc | H.Bar Feet
---------------------+-------------------------------------
46H | 16'
47H | 5 1/3'
48H | 8'
49H | 4'
4AH | 2 1/3'
4BH | 2'
4CH | 1 3/5'
4DH | 1 1/3'
4EH | 1'
* Control values and harmonic bars are related as follows.
vv | H.Bar Level
----------------------+---------------------------------
00H - 0EH | 0
0FH - 1CH | 1
1DH - 2AH | 2
2BH - 38H | 3
39H - 47H | 4
48H - 55H | 5
56H - 63H | 6
64H - 71H | 7
72H - 7FH | 8
❍General Purpose Controller 5 (Controller number 80)
Status 2nd byte 3rd byte
BnH 50H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
* Depending on the Control Message settings (Edit: System MIDI: Control Message).
❍General Purpose Controller 6 (Controller number 81)
Status 2nd byte 3rd byte
BnH 51H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
* Depending on the Control Message settings (Edit: System MIDI: Control Message).
❍General Purpose Controller 7 (Controller number 82)
Status 2nd byte 3rd byte
BnH 52H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
* Depending on the Control Message settings (Edit: System MIDI: Control Message).
❍General Purpose Controller 8 (Controller number 83)
Status 2nd byte 3rd byte
BnH 53H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
* Depending on the Control Message settings (Edit: System MIDI: Control Message).
❍Portamento Control (Controller number 84)
Status 2nd byte 3rd byte
BnH 54H kkH
n = MIDI channel number: 0H - FH (ch.1 - 16)
kk = source note number: 00H - 7FH (0 - 127)
*A Note-on received immediately after a Portamento Control message will change
continuously in pitch, starting from the pitch of the Source Note Number.
* If a voice is already sounding for a note number identical to the Source Note Number,
this voice will continue sounding (i.e., legato) and will, when the next Note-on is
received, smoothly change to the pitch of that Note-on.
* The rate of the pitch change caused by Portamento Control is determined by the
Portamento Time value.
*Not received by the Organ Part.
❍Effect 1 (Reverb Send Level) (Controller number 91)
Status 2nd byte 3rd byte
BnH 5BH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Reverb Send Level: 00H - 7FH (0 - 127)
*Not received by the Organ and Piano Part.
❍Effect 3 (Chorus Send Level) (Controller number 93)
Status 2nd byte 3rd byte
BnH 5DH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Chorus Send Level: 00H - 7FH (0 - 127)
*Not received by the Organ and Piano Part.
