Using the Advanced Functions
Advanced Functions
3. Press the [ENTER] button.
The save begins, and a message appears in the display.
In the above example, the current settings are stored in Registration 23.
If you do not want to store the settings in a registration, press the [EXIT]
button. The Basic screen returns to the display.
When saving to the registration is completed, a message indicating that it is
completed appears in the display, and the Basic screen returns to the
display.
Using a Control Pedal
You can connect a pedal switch (such as the optional DP-2) to the
CONTROL PEDAL jack on the VR-760’s rear panel to switch the rotary
effect, switch registrations, control the piano soft effect, turn external
sequencers on and off, and control other functions (p. 66).
Connecting an expression pedal (the optional EV-7) allows to use the pedal
to control the organ overdrive and D Beam functions.
You can set the function assigning to the control pedal (p. 66).
NOTE
Never turn off the power
while a REGISTRATION is
b
eing saved. Doing so may
damage the unit.
Simple Method for Storing to Registrations
You can store settings quickly by holding down the [WRITE] button and
pressing one of the REGISTRATION buttons [1]–[8]. This is convenient
when you have already determined the registration number you want to
save to.
1. Hold down the [WRITE] button and press the [BANK] button, then
press any of the REGISTRATION buttons [1]–[8].
The bank is confirmed.
Continue holding down the [WRITE] button.
2. Press any of the REGISTRATION buttons [1]–[8].
The settings are stored to the specified registration number. When the
process is finished, a message indicating that it is completed appears in
the display.
3. Release the [WRITE] button.
When saving to a registration in the same bank, use the following procedure
to store the settings.
1. Hold down the [WRITE] button and press a REGISTRATION button
[1]–[8].
When the save is finished, a message indicating that it is completed
appears in the display.
With certain pedals, the
action performed when you
press or release the pedal
may be reversed. In such
instances, switch the control
pedal polarity so that the
pedal functions properly (p.
65).
NOTE
Use only the specified
expression pedal (EV-7; sold
separately). By connecting
any other expression pedals,
you risk causing
malfunction and/or
damage to the unit.
