Panel Descriptions
Front Panel
fig.panÇçelF
ig.panelF
1. [MASTER VOLUME] knob
Adjust the overall volume (p. 20).
2. RHYTHM
RHYTHM [ON] button
Switch the rhythm on/off (p. 53).
[RHYTHM VOLUME] knob
Adjusts the volume level of the Rhythm part (p. 53).
3. D BEAM
D BEAM controller
You can modify the sound by moving your hand over
the D Beam controller (p. 49).
Selects one of the following three buttons.
[ROTARY SPEED] button
[OCTAVE] button
[GLIDE] button
4. Display
LED Display
This shows the temporary Registration number (p. 25).
Display
This shows the Tone names and the values of various
settings, etc (p. 25).
5. CURSOR, etc
CURSOR [ ], [ ], [ ], [ ] button
Press these to switch pages and to move the cursor (p.
26).
[DEC], [INC] button
This is used to modify values.
[ENTER] button
Use to finalize a value or execute an operation.
In addition, you can hold down this button while
pressing [EXIT] button to listen demo song (p. 27).
[EXIT] button
Press this to cancel operations, to exit from Edit mode,
and for other functions.
6. ONE TOUCH
This allows you to play only the part for the pressed
button (p. 28).
[ORGAN] button
[PIANO] button
[SYNTH] button
7. [V-LINK] button
Switches the V-LINK on/off (p. 61).
A
B
DC
67
A
34521
