76
Detailed Settings for Each Function (EDIT)
Convenient Functions
(UTILITY)
Checking the Installed Wave
Expansion Boards (SRX Info)
Check to confirm that the installed boards are being
recognized correctly.
1. Hold down the [EDIT] button, and press the
REGISTRATION [7] (UTILITY) button.
The Edit’s “UTILITY” screen is displayed.
2. Press CURSOR [ ] button to display the
following screen.
fig.06-02(SRXInfo)
The name of the installed Wave Expansion Board,
abbreviated to five characters, appears in the display.
“-----” appears next to the slot name when the slot has no
Wave Expansion Board in it.
3. Press the [EXIT] button to exit edit mode.
If “-----” appears next to the name of the slot in which the
board was installed, it may be that the wave expansion board
is not being recognized properly. Use the procedure in
“Turning Off the Power” (p. 19) to turn the power off, then
reinstall the wave expansion board correctly.
Transferring the VR-760’s
Settings to an External MIDI
Device (Bulk Dump)
You can transfer the contents of Registrations and the VR-
760’s system settings to an external MIDI device. This
operation is called “bulk dump.”
Connect the VR-760 to Your Sequencer
1. Make sure that the power of the VR-760 and your
sequencer is off.
Turn off the power of the VR-760 and the other device before
making connections. If you connect an external device when
the power is turned on, damage or malfunctions may occur.
2. Use commercially-available MIDI cables to
connect the VR-760 to your sequencer.
fig.06-03(Connecting)
* Connect the VR-760’s MIDI OUT connector to the
sequencer’s MIDI IN connector
3. Turn on the power of the external sequencer and
the VR-760.
4. Turn off the Thru function of your sequencer.
MIDI IN
