Settings Common to All Modes (System Mode)
KBD
fig.05-06_50
KBD Sens (Keyboard Sensitivity)
Adjusts the keyboard’s touch.
Value
LIGHT: Light weight synthesizer keyboard like
MEDIUM: Standard
HEAVY: Acoustic piano simulation
KBD Velocity (Keyboard Velocity)
Specifies the velocity value that will be transmitted when you play
the keyboard. If you want actual keyboard velocity to be
transmitted, set this to “REAL.” If you want a fixed velocity value to
be transmitted regardless of how you play, specify the desired value
(1–127).
Value: REAL, 1–127
After Sens (Aftertouch Sensitivity)
Specifies the Aftertouch sensitivity. Higher values will allow
Aftertouch to be applied more easily. Normally you will leave this at
“100.”
Value: 0–200
Local Sw (Local Switch)
The Local Switch determines whether the internal sound generator is
disconnected (OFF) from the controller section (keyboard, pitch
bend/modulation lever, knobs, buttons, Time Trip Pad, D Beam
controller, pedal, and so on); or not disconnected (ON). Normally
this is left “ON,” but if you wish to use the V-Synth’s keyboard and
controllers to control only external sound modules, set it to “OFF.”
Value: OFF, ON
Remote KBD Sw (Remote Keyboard Switch)
Set this parameter “ON” when you want to use an external MIDI
keyboard instead of the V-Synth’s keyboard. In this case, the MIDI
transmit channel of the external MIDI keyboard can be set to any
channel. Normally you will leave this parameter “OFF.”
Turn this “ON” when you want to control the V-Synth from an
external MIDI device when performing with the Arpeggiator (p.
24).
TT Pad/Knob
fig.05-07_50
X Assign-XY
Specifies the MIDI controller number that will be transmitted by
movements in the ‘X’ (horizontal) direction when the Time Trip pad
is in XY mode.
Value
OFF: No message will be transmitted.
CC01–31, 33–95: Controller numbers 1–31, 33–95
Y Assign-XY
Specifies the MIDI controller number that will be transmitted by
movements in the ‘Y’ (vertical) direction when the Time Trip pad is
in XY mode.
Value
OFF: No message will be transmitted.
CC01–31, 33–95: Controller numbers 1–31, 33–95
X Assign-TT (X Assign-Time Trip)
Specifies the MIDI controller number that will be transmitted by
movements in the ‘X’ (horizontal) direction when the Time Trip pad
is in Time Trip mode.
Value
OFF: No message will be transmitted.
CC01–31, 33–95: Controller numbers 1–31, 33–95
Y Assign-TT (Y Assign-Time Trip)
Specifies the MIDI controller number that will be transmitted by
movements in the ‘Y’ (vertical) direction when the Time Trip pad is
in Time Trip mode.
Value
OFF: No message will be transmitted.
CC01–31, 33–95: Controller numbers 1–31, 33–95
For details on control change messages, refer to “MIDI
Implementation” (p. 153).
