51
flashing
Effect parameter settings
Here's how to set the effect parameters.
1.If the effect parameter that you wish to adjust is not
displayed, press the [EFF 1] key (or the [EFF 2] key)
twice.
One of the parameters of that effect type will appear.
2.Press the [EFF 1] key (or the [EFF 2] key) several times
to display the desired parameter.
The parameters that appear will differ, depending on
the effect type that is selected.
4.If you wish to adjust another parameter, repeat from
<step 2>.
5.When you are finished making settings, press the [EXIT/
NO] key twice to exit Effect Edit mode.
Muting an effect
You can mute the effect sound of effect 1 or effect 2.
* To mute the effect sound:
Hold down the [SHIFT] key and press the [EFF 1] key (or
[EFF 2] key).
The effect sound of effect 1 (or effect 2) will be muted,
and the dry sound will be heard.
When muting is on, the [EFF 1] key (or [EFF 2] key) LED is
off.
* To cancel muting:
Once again hold down the [SHIFT] key and press the [EFF
1] key (or [EFF 2] key).
The dry sound will change back to the effect sound.
When mute is turned off, the [EFF 1] key (or [EFF 2] key)
LED is off.
flashing
3.Use the [JOG] dial to adjust the value.
For details on the meaning and range of each
parameter, refer to "Effect parameter details" on the next
page.
Effect parameter details
The parameters that can be adjusted will depend on the parameter type.
Reverb effect parameters (parameter type: REVERB)
For effect types 1--24 of the preceding "Effect type" table, the following four parameters can be adjusted.
1.Eff Level Adjust the effect return level: 0~99
2.Rev Time Adjust the length of reverberation. Range: 0.1--9.9 seconds
3.Pre Delay Adjust the time from the original sound until reverberation begins. Range: 0--100 ms
4.Hi Ratio Adjust the decay ratio of the high frequencies. Range: 0--10
5.E/R Level Adjust the volume of the early reflections. Range: 0--99
Delay+reverb effect parameters (parameter type: DELAY+REVERB)
For effect types 25--28 of the preceding "Effect type" table, the following four parameters can be adjusted.
1. Eff Level Adjust the effect return level: 0~99
2. Delay Time Adjust the delay time: Range: 1--230 ms
3. Feedback Adjust the number of delay repeats. Range: 0--99
4. Delay Bal Adjust the delay balance. Range: 0--99
5. Rev Time Adjust the length of reverberation. Range: 0.1--9.9 seconds
Delay effect parameters (parameter type: DELAY)
For effect types 29 and 30 of the preceding "Effect type" table, the following four parameters can be adjusted.
1. Eff Level Adjust the effect return level: 0~99
2. Delay Time Adjust the delay time. Range: 1--680 ms
3. Feedback Adjust the number of delay repeats. Range: 0--99
4. Hi Ratio Adjust the decay ratio of the high frequencies. Range: 0--10
5. Filter Adjust the tone of the delay sound. Range: L9~L1, OFF, H1~H9
* L1~L9 = LPF (larger numbers will lower the cutoff frequency)
* H1~H9 = HPF (larger numbers will raise the cutoff frequency)
