ASSIGNABLE BLOCK AND PEDAL SWITCH FUNCTIONS CHART
For 7, 8, 10, 28, 31 —
The ASSIGNABLE Block Pedal Switch has no
function.
For 3, 9 —
Pressing [MEMORY] calls up either BANK/
NUMBER select or ON/OFF, depending on
which was last selected with the Pedal Switch
(pressing twice selects ON/OFF; pressing once
selects BANK/NUMBER).
For 15, 21 —
The ASSIGNABLE Block Pedal Switch is used
for MIN/MAX VOLUME or AUTO VOLUME
and cannot be used for BANK select or switch-
ing between BANK/NUMBER select and ON/
OFF.
For 5, 6, 11, 12 —
Despite the LED being lit (or flashing), these
functions are not available.
For 28 —
Only measure reverse (n) and forward (m) are
available.
For 25, 26 —
The functions of Pedal Switches 1–5 differ
between the two settings. The functions also
differ between song/pattern playback and
stopped conditions.
For 29 —
The functions of Pedal Switches 1–5 are the
same for pattern playback and stopped condi-
tions.
For 25, 29 —
The ASSIGNABLE Block Pedal Switch can be
used to switch between the two settings, and
(when held down) can be used for the Root
Select function.
For 26 —
The ASSIGNABLE Block Pedal Switch (when
held down) can be used for the Triggered Run
function.
If the ASSIGNABLE
… in the condition below:
… and one of the following
… the following result occurs:
Block is set to: Pedal Switches is pressed:
BACKING CONTROL When attempting a Memory Pedal Switches 1, 2 The selected song or pattern is called
Job mode operation (song/pattern number up and the Job operation is aborted
(with the Pattern or Song selected) (operation returns to Memory mode).
mode selected).
MEMORY When attempting a Song Job Pedal Switches 1–5, The Job operation is aborted and
BANK/NUMBER mode operation ASSIGNABLE Pedal Switch operation returns to Song mode).
(with the Memory mode (effect program bank/number
selected). select)
CHORD RECALL When attempting a Memory Pedal Switches 1–4 The Job operation is aborted and
Job mode operation (chord select) operation returns to Memory mode.
(with the Pattern or Realtime (Realtime Recording is also still
Recording mode selected). active if this had been selected.)
This chart shows how pressing various Pedal Switches affects some specific operations.
