Model LR16 [Introduction/Overview]
12
Recorder section (main unit) features
• Built in a large capacity hard disk drive which allows up to 16 track digital
recording (approx. 16 hour recording in 44.1 kHz/16 bit, 80GB).
• In addition to up to 16 track recording, stereo mix recording is possible.
Also, multitracks and stereo mix can be recorded simultaneously.
• Mark function allows locating to a mark.
• 132 x 64 dot graphic LCD allows viewing the level meters and information at a
glance.
• Memory play function is provided, allowing instant playback using the numeric
keys as well as a footswitch (the footswitch function can be selected using the
System menu of the MENU mode).
• Punch in/out function using the panel keys as well as a footswitch.
• By connecting a computer to the [USB PC] port, you can transfer audio files (note
that you cannot simultaneously use the [USB HOST] port).
• By connecting a FAT16 and FAT32 formatted USB flash memory stick, you can
copy audio files or version upgrade file.
• From the [MIDI OUT] port, MTC (MIDI Time Code) can be output, allowing
synchronization with external MIDI devices (the MTC frame rate can be selected
between 25 fps and 30 fps via the System menu of the MENU mode).
• 3-band (High/Mid/Low) input equalizer on each input channel.
• Insertion point on input channel 1 through 8, allowing connection to an external
comp/limiter, etc.
• XLR-phone combo type connector provided on each input channel, allowing mic or
line connection. In addition, phantom power can be supplied to each XLR
connector, allowing use of a condenser microphone. (You can turn on or off
phantom power in eight channel groups.)
• Four group outputs allow connection to an external mixer or multitrack recorder.
• Aux and effect sends allow connection to an external effect unit, a stage monitor
system, etc.
