70
Model LR16 [Recorder functions / Project management]
Copying a stereo mix file to an external medium
You can copy a stereo mix file in the "2 mix"
folder of the current project to an external
USB memory stick. You can copy all or any
desired stereo mix files.
<Note>:
Connect a FAT16- or FAT32-format-
ted USB memory stick to the [USB HOST] port
of the main unit before executing the follow-
ing procedure.
INSERT
INSERTINSERTINSERTINSERTINSERTINSERTINSERT
INPUT
AUX SEND (-2dBu)
EFF SEND (-2dBu)
GROUP (+4dBu)
R STEREO OUT (+4dBu) L
ST MIX OUT (-10dBV)
USB
MIDI OUT
FOOT SW CONTROLLERPANEL LOCK
LOCK
PHANTOM
POWER
USB memory stick
(1) Press the [ENTER] key to bring up the
MENU screen.
When you bring up the MENU screen for
the first time, "Mark point" is highlighted.
(2) Use the [MENU] dial to highlight "Project"
and press the [ENTER] key.
The display now shows the project menu.
(4) Use the [MENU] dial to highlight
"[EXECUTE]" and press the [ENTER] key.
(5) Press any operation key.
The LR16 exit the MENU mode and the
display returns to the Home screen.
After completing exporting data, the follow-
ing popup appears.
<Note>:
If the data of a project with the
same name exists on the USB memory
stick when you attempt to execute ex-
porting the project data by pressing the
[ENTER] key, the following popup ap-
pears.
To overwrite the existing data, press the
[ENTER] key. If you do not want to over-
write the existing data, press the [EXIT/
NO] key to cancel exporting data.
You can export data without overwrit-
ing the existing data after changing the
project name.
The LR16 starts exporting data to the USB
memory stick and the display shows the
progress.
The display also shows the approximate fin-
ish time and remaining size of the USB
memory stick.
<When a USB memory stick is not FAT16- or
FAT32-formatted>
<Note>:
If no USB memory stick is connected,
or if a USB memory stick is not FAT16- or
FAT32-formatted, or if no stereo mix file ex-
ists, the appropriate popup as below is shown
and the LR16 cannot enter the Export mode.
<When no USB memory stick is set>
<When no stereo mix file exists>
