Model LR16 [Specifications]
Inputs/Outputs
Specifications
0dBV = 1.0 Vrms, 0dBu = 0.775 Vrms
Reference level: -20dBfs
Input and Output (Main unit)
[MIC INPUT (1 - 16)]
Connectors: XLR3-31, balanced
(combo)
Nominal input level: -60dBu ~ -12dBu
Input impedance: more than 1.5kΩ
Phantom Power: P48V (1-8ch & 9-16ch
switchable, on/off)
[LINE INPUT (1 - 16)]
Connectors: ø6.3mm TRS phone,
balanced (combo)
Nominal input level: -40dBu ~ +8dBu
Input impedance: more than 10kΩ
[INSERT (1 - 8)]
Connectors: ø6.3mm TRS phone,
(Tip: Output, Ring: Input)
Load impedance: more than 10kΩ
Nominal output level: -10dBV
Input impedance: more than 10kΩ
Nominal input level: -10dBV
[STEREO BUS OUT (L, R)]
Connectors: XLR3-31, balanced
Reference output level:+4dBu
Load impedance: more than 10kΩ
[GROUP BUS OUT (1 - 4)]
Connectors: ø6.3mm TRS phone,
balanced
Reference output level:+4dBu
Load impedance: more than 10kΩ
[AUX SEND (1 - 3)]
Connectors: ø6.3mm phone,
unbalanced
Reference output level:-2dBu
Load impedance: more than 10kΩ
[EFFECT SEND]
Connector: ø6.3mm phone,
unbalanced
Reference output level:-2dBu
Load impedance: more than 10kΩ
[STEREO MIX OUT (L, R)]
Connectors: RCA, unbalanced
Reference output level:-10dBu
Load impedance: more than 10kΩ
[FOOT SW]
Connector: ø6.3mm phone,
Level: TTL level (unlatched type)
[USB (PC)]
Device: USB2.0 Hi-speed for PC
connection
Connector: B type
[USB (HOST)]
Device: USB2.0 Hi-speed for
storage connection
Connector: A type
[MIDI OUT]
Connector: DIN 5-pin
[TO CONTROL BOX]
Connector: RJ45 (CAT5, straight)
Input and Output (Controller unit)
[PHONES]
Connector: ø6.3mm Stereo Phone
Load impedance: more than 32Ω
[MONITOR OUT (L, R)]
Connector: ø6.3mm Phone,
unbalanced
Reference output level:-12dBV
Load impedance: more than 32Ω
[SUB IN (L, R)]
Connector: RCA, unbalanced
Reference input level: -10dBV
Input impedance: more than 10kΩ
[TO I/O BOX]
Connector: RJ45 (CAT5, straight)
Recording/Playback
Recording media: Internal 3.5” HDD
Sampling frequency: 44.1/48kHz
Quantization: 16bit/24bit
File system: FAT32 (WAV)
Number of recording tracks: 1 - 16
