Model LR16 [Recorder function / Other functions]
Adjusting the display contrast
Other functions
If the display is difficult to see, you can adjust
the display contrast by rotating the [MENU]
dial while the LR16 is turned on.
Rotating the [MENU] dial counterclockwise
increases the contrast. Rotating the [MENU]
dial clockwise decreases the contrast.
<Memo>: The contrast setting remains in
effect even if you turn off the LR16.
If you initialize the system memory via the
"Sys default memory" menu item of the
"System" menu, the contrast reverts back
to the default setting.
Setting the footswtich function
You can select the function of a footswitch
connected to the [FOOT SW] jack on the rear
panel of the main unit between the punch
in/out function and memory play start/stop
function.
P I/O
A connected footswitch acts as the
punch in/out switch.
A connected footswitch acts the same
as the associated memory key. Press-
ing the footswitch starts or stop
memory play.
(1) Press the [ENTER] key to bring up the
MENU screen.
When you bring up the MENU screen for
the first time, "Mark point" is highlighted.
(2) Use the [MENU] dial to highlight "System"
and press the [ENTER] key.
The display now shows the system menu
screen.
(3) Use the [MENU] dial to highlight "Foot SW"
and press the [ENTER] key.
The current setting starts flashing and you
can now change the setting (by default,
"P I/O" flashes).
(4) Use the [MENU] dial to highlight the desired
option and press the [ENTER] key to
confirm the setting.
(5) Press the [STOP] key to exit the MENU
mode.
You can select from the following options.
MEM 0
I
I
MEM 9
<Memo>: If you initialize the system
memory via the "Sys default memory"
menu item of the "System" menu, the
footswitch function reverts back to the
default setting (P I/O).
