HUAWEI MG323 GSM M2M Module
AT Command Interface Specification Commands for Hardware Control
Issue 02 (2010-11-23)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
191
14 Commands for Hardware Control
This chapter describes the AT commands that operate the hardware.
14.1 AT+CALA
The AT+CALA command sets the alarm time on the ME. When the set alarm time is
reached, the alarm sends a URC, and the alarm time is reset to "00/01/01,00:00:00".
The alarm provides two functions:
z
Timed notification SM: When the module is not powered off, a timed SM can be
unsolicitedly reported through +CALA.
z
Clock mode: When the module is powered off, the clock function can be used to
wake up the module. When the module is powered off, and the set alarm time is
reached, the module is waken up, and the +CALA is unsolicitedly reported.
14.1.1 Checking the Parameter Range Supported by This
Command
Test
command
AT+CALA=?
Function
Checks the parameter range supported by this command.
Response
z
In case of successful execution:
<CR><LF>+ CALA: (list of supported<n>s), (list of supported<type>s),
(list of supported<tlength>s) <CR><LF><CR><LF>OK<CR><LF>
z
In case of an error during command execution:
<CR><LF>ERROR:<CR><LF>
z
In case of an error related to the MT: <CR><LF>+CME ERROR:
<err><CR><LF>
Parameter description
<n>: integer, which indicates the index of the alarm clock array.
