HUAWEI MG323 GSM M2M Module
AT Command Interface Specification Commands for Status Control
Issue 02 (2010-11-23)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
34
<indDescr> <indValue>
99: unknown or unmeasurable.
0: Short messages are not encrypted. “ciphcall”: encryption status
change indicator. This indicator
may be disabled by the EFad
(administrative data) file data of
the SIM card.
1: Short messages are encrypted.
0: Not registered
1: EF-OPL，EF-PNN（the longest character: 24）
2：Long and short string format, Common PCN
Handset Specification(CPHS)
3: Operator name with NITZ message. Short string
format only display when the EFopshort of CPHS is
usable.
4: Operator name with ME stored.
"eons": Enhanced Operator
Name String (EONS) indicator.
The presentation of the "eons"
indicator is determined by
network activities. For example,
the indicator appears every time
a location update occurs or a
NITZ message is sent, no matter
whether or not the status of the
EONS message has changed.
The EONS tables are stored in
the SIM card and will be read at
power-up. 0–5 indicates the
priority of the operator name
source (GSM 22.101).
5：Broadcast MCC-MNC（digital format）
“nitz”: network and time zone
indicator. When the network or
time zone with which the MT
registers changes, the network
sends a time indicator.
The related parameters are <nitzUT>, <nitzTZ>,
and <nitzDST>.
3.3.2 Reading the Current Event Reporting Mode
Read
command
AT^SIND?
Function
Reads the current event reporting mode.
Response
z
In case of successful execution: <CR><LF>^SIND:
<indDescr>,<mode>,<indValue>[^SIND:
<indDescr>,<mode>,<indValue>[…]] <CR><LF>
<CR><LF>OK<CR><LF>
z
In case of an error: <CR><LF>ERROR <CR><LF>
z
In case of an error related to the MT: <CR><LF>+CME ERROR:
<err><CR><LF>
Parameter description
<mode>: integer. This parameter controls the reporting of a single event.
