Vocal Designer
Equalizer:
Adjusts the character of the low, mid, and high-frequency ranges.
The EQ settings are shown by the graph in the middle of the screen.
fig.06d-12-ps.eps
EQ
Parameter
Value Description
Mic/EQ Switch
OFF, ON
Turns the equalizer on/off.
3 Band EQ
EQ Low Freq (EQ Low Frequency)
50, 63, 80, 100, 125,
160, 200, 250, 315,
400, 500, 630, 800,
1000, 1250, 1600,
2000, 2500, 3150,
4000 Hz
Specifies the center frequency at which the low-frequency range
will be adjusted.
EQ Low Gain
-15– +15 dB Specifies the gain (amount of boost or cut) for the low-frequency
range. Positive settings will boost the low-frequency range.
EQ Mid Freq (EQ Mid Frequency)
50, 63, 80, 100, 125,
160, 200, 250, 315,
400, 500, 630, 800,
1000, 1250, 1600,
2000, 2500, 3150,
4000, 5000, 6300,
8000, 10000, 12500,
16000, 20000 Hz
Specifies the center frequency at which the mid-frequency range
will be adjusted.
EQ Mid Gain
-15– +15 dB
Specifies the gain (amount of boost or cut) for the mid-frequency
range. Positive settings will boost the mid-frequency range.
EQ Mid Q
0.3, 0.4, 0.6, 0.8, 1.0,
1.5. 2.0, 2.5. 3.0, 3.5,
4.0, 5.0, 6.0, 7.0, 8.0,
10.0, 12.0, 14.0,
16.0, 18.0, 20.0
Specifies the width of the mid-frequency range. Higher settings will
narrow the range.
EQ Hi Freq (EQ High Frequency)
2000, 4000, 5000,
6300, 8000, 10000,
12500, 16000, 20000
Hz
Specifies the center frequency at which the high-frequency range
will be adjusted.
EQ Hi Gain (EQ High Gain)
-15– +15 dB
Specifies the gain (amount of boost or cut) for the high-frequency
range. Positive settings will boost the high-frequency range.
