Playing Sounds
fig.01-06e
Procedure
fig.01-07
1. Press [VALUE] to make the PATCH indicator lights up.
Press the knob several times, until the PATCH indicator lights up.
2. Turn [CATEGORY/BANK] to choose the bank (USER, PST-A/B/C/D,
GM, EXP-A/B)
3. Turn [VALUE] to choose a Patch.
* You can listen to the selected patch sound by holding down [VOLUME]. At this time, the
currently selected preset bank USr (USER) and the patch number appear in alternation on
the display.
Bank page Description
USER p. 124 There are 128 patches stored in memory, which you can overwrite with patches you create your-
self.
PSTA/B/C/D (PRESET) p. 125 There are 512 patches (with 128 Patches in a single bank) stored in memory, which cannot be
overwritten
GM (General MIDI) p. 129 These are patches for the General MIDI System, which is designed to standardize the specifica-
tions for MIDI functions for all manufacturers and models. There are 128 patches stored in mem-
ory, which cannot be overwritten.
EXP-A/B --- These are banks for use with Wave Expansion Boards installed in the slots. Patches are stored in
memory on the separately available Wave Expansion Board, and cannot be overwritten.
1
2
USER
PST-A
PST-B
PST-C
PST-D
GM
EXP-A
EXP-B
Patch
3
64
Patch number
Bank
Patch Patch Patch
Patch Patch Patch
Patch
1, 3
2
You cannot select EXP-A or
EXP-B unless a Wave
Expansion Board is
installed into the
corresponding slot.
Turning [VALUE] rapidly
makes the value change in
large increments.
