Using the XV-2020 Effects
Using the XV-2020
Effects
37: CHORUS -> FLANGER
fig.02-037m
38: CHORUS/DELAY
The parameters are the same as for “35: CHORUS -> DELAY.”
However, the Delay Balance parameter adjusts the volume balance
between the direct sound and the delay sound.
fig.02-038m
39: FLANGER/DELAY
The parameters are the same as for “36: FLG -> DELAY.” However,
the Delay Balance parameter adjusts the volume balance between the
direct sound and the delay sound.
fig.02-039m
40: CHORUS/FLANGER
The parameters are the same as for “37: CHO -> FLANGER.”
However, the Flanger Balance parameter adjusts the volume balance
between the direct sound and the flanger sound.
fig.02-040m
note*1
Parameter Value Description
Cho Delay 0.0-100.0 ms Adjusts the time until the chorus is
heard.
Cho Rate 0.05-10.00 Hz Modulation frequency of the chorus
effect
Cho Depth 0-127 Modulation depth of the chorus effect
Cho Balance # D100:0W-
D0:100W
Volume balance between the direct
sound (D) and the chorus sound (W)
Flg Rate 0.05-10.00 Hz Modulation frequency of the flanger
effect
Flg Depth 0-127 Modulation depth of the flanger effect
Flg Feedback -98-+98 % Adjusts the amount of the flanger
sound that’s fed back into the effect.
Negative (-) settings invert the phase.
Flg Delay 0.0-100.0 ms Adjusts the time until the flanger
sound is heard.
Flg Balance # D100:0W-
D0:100W
Adjusts the volume balance between
the sound sent through the flanger (W)
and the sound that’s not sent through
the flanger (D).
Level 0-127 Output level
Feedback
Flanger
L in
R in
L out
R out
Balance W
Balance W
Balance D
Balance D
Chorus
Balance W
Balance W
Balance D
Balance D
R in R out
L in L out
Feedback
Balance W
Balance D
Balance W
Balance D
Chorus
Delay
R in R out
L in L out
Feedback
Feedback
Balance W
Balance D
Balance W
Balance D
Flanger
Delay
R in R out
L in L out
Feedback
Balance W
Balance D
Balance W
Balance D
Chorus
Flanger
Dotted eighth note
Half-note triplet
Eighth note
Half-note triplet
Quarter note
Dotted quarter note
Half note
Sixteenth note
Eighth-note triplet
Dotted sixteenth note
