94
Establishing Settings for an Entire
XV-2020 (SYSTEM COMMON)
SYSTEM COMMON
Parameter Value Description
MASTER LEVEL 0–127 Adjusts the volume of the entire XV-2020.
MASTER TUNE 415.3–466.2 Hz Adjusts the overall tuning of the XV-2020. The setting is expressed as the fre-
quency played by the A4 key.
PATCH REMAIN
(Patch Remain Switch)
OFF, ON This specifies whether you want the notes that are sounding to remain (ON)
or turn off (OFF) when you select a new Patch or Rhythm Set in Patch mode.
In addition, when “ON” is selected, the Volume and Pan data, and the Key
Mode and other settings received via MIDI (CC 5, 7, 10, 65, 68, 71–74, RPN 0,
1, 2, MONO ON, POLY ON) are passed on.
MASTER KEY SHIFT -24–+24 Shifts the overall pitch of the XV-2020 in semitone steps.
CLOCK SOURCE
(System Clock Source)
INT, MIDI, USB Specifies the tempo clock of the system.
INT: The internal clock
MIDI: An external clock received via MIDI IN connector
USB: An external clock received via USB connector
TEMPO
(System Tempo)
20–250 Sets the system tempo. When Clock Source is set to “MIDI” or “USB,” the
tempo will synchronize to the clock messages received from an external de-
vice, so the tempo value will be ignored.
PERFORM CTRL CH
(Performance Control Channel)
1–16, OFF When changing Performances by MIDI messages from the external device,
set the transmit channel of the external device and this channel to the same
channel.
* When you perform a Factory Reset operation, Control Channel is reset to “16.”
PATCH RCV CH
(Patch/Rhythm Set Receive Channel)
1–16 Set this channel to use an external MIDI device (such as a MIDI keyboard) for
playing Patches and Rhythm Sets, or to have Patches or Rhythm Sets
changed as the result of MIDI messages.
RCV PC
(Receive Program Change Switch)
OFF, ON Specifies whether Program Change messages will be received (ON), or not
(OFF).
RCV BS
(Receive Bank Select Switch)
OFF, ON Specifies whether Bank Select messages will be received (ON), or not (OFF).
SYSTEM CTRL SRC 1–4
(System Control Source1–4)
OFF, CC01–31,
33–95, BEND,
AFTER
These settings allow you to choose four MIDI controllers for global use when
controlling the parameters of any Patch or Performance. The settings in each
Patch or Performance will determine whether the two controllers you choose
here will actually be used. In each Patch or Performance, you will also need
to specify the parameters to be controlled.
OFF: No controller is used.
CC01–95: Controller numbers 1–95 (except for 32)
BEND: Pitch Bend
AFTER: Aftertouch
