Setting Up
DTXTREME III Owner’s Manual
27
■ Trigger Setup List
* In the default setting, “PRE: 01 SP Wide” for Special Drum Set is selected.
The original factory settings of this instrument’s User Memory
(page 76) can be restored as follows. For each of all modes,
you can set whether or not User Memory data is initialized.
1
Press the [UTILITY] button to enter the
Utility mode.
2
Press the [F6] FACTSET button to call up
the Factory Set display.
1 Checkbox
If you enter a checkmark for a mode name in the display
(in step 3 below), executing the Factory Set will reset the
User Memory data or settings of the corresponding mode
to the initial factory settings. For those modes without
checkmarks, the User Memory data or settings will be
maintained even if Factory Set is executed.
3
Move the cursor to the checkbox of the
desired mode then enter or remove the
checkmark by using the data dial, [INC/
YES] button or [DEC/NO] button.
4
Press the [ENTER/STORE] button.
The display prompts you for confirmation.
Press the [DEC/NO] button or [EXIT] button to cancel
the operation.
5
Press the [INC/YES] button to execute the
Factory Set operation.
After the Factory Set has been completed, a “Com-
pleted” message appears and operation returns to the
original display.
No. Name Description
PRE: 01 SP Wide
For Special
Drum Set
Wide dynamic range. This setting is designed for maximum expressive control, allowing
performance subtleties over a wide dynamic range.
PRE: 02 SP Normal Normal setting
PRE: 03 SP Narrow
Controlled dynamic range delivers stable trigger detection. This setting is designed for
producing a smoother, more uniform sound with reduced volume fluctuations.
PRE: 04 STD Wide
For Standard
Drum Set
Wide dynamic range. This setting is designed for maximum expressive control, allowing
performance subtleties over a wide dynamic range.
PRE: 05 STD Normal Normal setting
PRE: 06 STD Narrow
Controlled dynamic range delivers stable trigger detection. This setting is designed for
producing a smoother, more uniform sound with reduced volume fluctuations.
PRE: 07 DT10/20 — Use for DT10/20 drum trigger systems applied to acoustic drums.
USR: 01 – 05 User Trigger — Allows creation of custom trigger setups.
Resetting the User Memory to the Initial Factory Settings
• When the factory settings are restored, all the data you created in each
mode will be erased. Make sure you are not overwriting any important
data. Be sure to save all important data to a USB storage device before
executing this procedure (page 114).
CAUTION
1
•For Factory Set operations that take longer to process, a message
“Executing...” or “Please keep power on.” appears during process-
ing. While such a message is shown (while data is being written to
Flash ROM), never attempt to turn off the power. Turning the power
off in this state results in loss of all user data and may cause the
system to freeze (due to corruption of data in the Flash ROM). This
means that this instrument may not be able to start up properly,
even when turning the power on next time.
CAUTION
