5.2 PBX Settings for Inband Integration
156 Installation Manual
• Call Progress Tone Detection for Inband Mode
Specifies whether to detect "Call Progress Tone".
5.2.3 PBX Interface Parameters
The following items can be programmed using KX-TVM Maintenance Console under "System
Parameters" by selecting the "Parameters" tab.
PBX Environment
• PBX Type
Specifies the type of PBX which is connected to the VPS.
• Integration Mode
Select "Inband". If PBX type is set to the Panasonic KX-T series, the Inband Signalling
parameters are set automatically and should not be altered.
SEQUENCE CODES
• Maximum Extension Number Length
Specifies the maximum number of digits that the connected PBX recognises as an extension
number.
• Extension Number of VPS Port
Specifies the extension number for each VPS port on the connected PBX.
Note
• Extension numbers of the VPS ports will automatically be assigned when the PBX type has
been changed.
• Operator Transfer Sequence
Tells the VPS how to transfer a call to the operator.
Example: FTX [hookswitch flash dial tone dial (operator) extn.]
• Extension Transfer Sequence
Tells the VPS how to transfer a call to an extension.
Example: FTX [hookswitch flash dial tone dial extn.]
• Alternate Extension Transfer Sequence
Tells the VPS how to transfer a call to an extension that belongs to the "Alternate Extension
Group". This is useful for extensions that need a special transfer procedure (i.e., blind transfer)
D Disconnect
F Hookswitch Flash
R Ring Detection
T Dial Tone Detection
X Dial Extension
, Dialling Pause (default 1 s)
; Dialling Pause (default 3 s)
0-9, , #
DTMF Tones
