1.3 Specifications
28 Installation Manual
1.3 Specifications
Specification KX-TVM50 KX-TVM200
Hardware Available Port Cards 2-Port Hybrid Expansion Card (KX-
TVM502)
4-Port Digital Expansion
Card (KX-TVM204)
Number of Port Card Slots 2 6
Additional PBX Interface
—
VM Link
(currently
unavailable)
Data Ports USB (built-in)
LAN (optional)
Modem (optional)
USB (built-in)
LAN (built-in)
Modem (optional)
Additional Hardware Mode Switch
Telephone Line
Connections
• APT/DPT Integration:
4-conductor cable
• Inband/No Integration:
2-conductor cable
4-conductor cable
Message Recording
Medium
Flash Memory
Internal Hard Disk Drive
(HDD)
Recording Capacity
4 h (expandable to 8 h)
*1
1000 h
Main CPU 32-bit microprocessor
Compression Rate 32 Kbps
Internal Modem Type V.90
Dialling Method DTMF
Flash Time 100 ms/300 ms/600 ms/900 ms
(programmable)
–
CPC Detection None/6.5 ms/150 ms/300 ms/450 ms/
600 ms (programmable)
–
Line Type • Loop start minimum Loop
Current: 20 mA
• Minimum Line Voltage: 7 V DC
• Minimum Ringing Voltage: 40 V
AC
–
Extension Numbering 2 to 5 digits (programmable)
Pause Length 100 ms to 9900 ms (programmable)
Message Waiting Lamp • APT/DPT Integration: Data Line
of APT/DPT Interface
• Inband Integration:
Programmable DTMF sequence
Data Line of DPT Interface
