Editing Songs
This function extracts a specified sequencer data area from a phrase
track or pattern and moves it to the same Song position of another
phrase track or pattern. Additionally, just as with Standard MIDI
File Format 0, when sequencer data from multiple MIDI channels is
recorded on one track, you can also assign one MIDI channel to a
single phrase track.
For details on the settings, refer to
Basic Operation for Track
Editing
(p. 133).
fig.Extract
Extracting and Moving a Part of
Sequencer Data (Extract)
Parameter
Value Explanation
Src Track/
Pattern
TRK 1–16, PTN001–
100
Phrase track or pattern
from which the sequencer
data will be extracted
TRK 1–16:
Specified
phrase track
PTN001–100:
Specified
pattern
* After Extract is executed,
the selected sequencer data
no longer remains on this
phrase track or pattern.
Ch/Part
ALL, Ch 1–16 MIDI channel(s) of the
data to be extracted
ALL:
Extracts all se-
quencer data.
Ch 1–16:
Extracts just
the sequencer data of a
specific MIDI channel.
* If you set “Status” to
“System Exclusive,”
“Tune Request” or “Pat-
tern Call,” this parameter
will not be available.
Measure
0001– Range of measures from
which sequencer data will
be extracted
If you set “For” to
“ALL,” all measures
will be specified.
For 1–ALL
Dst Track/
Pattern
TRK ALL, TRK 1–16,
PTN001–100
Move-destination track or
pattern
TRK ALL:
According to
its MIDI channel, the se-
quencer data will be di-
vided among phrase
tracks 1–16.
TRK 1–16:
Specified
phrase track
PTN001–PTN100:
Specified pattern
Extract
Mode
MIX, REPLACE Specifies whether you
want to keep the sequenc-
er data at the destination.
MIX:
The data at the
destination will com-
bine with the extracted
data.
REPLACE:
The data at
the destination will be
erased and replaced by
the extracted data. Only
the sequencer data of
the MIDI channel speci-
fied by the Channel pa-
rameter will be the
object of the operation.
Sequencer data of all
other MIDI channels
will be unaffected.
Status ALL, Note,
Poly Aftertouch,
Control Change,
Program Change,
Channel Aftertouch,
Pitch Bend,
System Exclusive,
Tune Request,
Pattern Call
Type of data to be extract-
ed
When “Status” is “Note” or “Poly Aftertouch”
Range Min
0 (C -)–127 (G9) Range of note numbers to
be extracted
You can also specify the
key range by pressing
keys on the keyboard.
Range Max
When “Status” is “Control Change”
Range Min 0–127 Range of controller num-
bers to be extracted
Range Max
When “Status” is “Program Change”
Range Min 1–128 Range of program num-
bers to be extracted
Range Max
Parameter
Value Explanation
