Playing in Performance Mode
The currently selected part is called the “current part.”
1.
In the PERFORM MIXER screen, press [CURSOR] to move
the cursor to the Part number.
fig.PartSelect2
2.
Use the VALUE dial or [INC] [DEC] to select the part.
You can also select the part by pressing [SELECT] to make it
light and pressing PART/TRACK [1]–[8].
* To select parts 9–16, press [9-16] to make it light, and then press
PART/TRACK [1]–[8].
You can switch the patch that is assigned to a part.
1.
Select the part whose sound you want to switch.
2.
Press [CURSOR] to move the cursor to the patch number or
patch group.
fig.PatchNumSelect
3.
Use the VALUE dial or [INC] [DEC] to select a patch.
Selecting the Rhythm Set
1.
Select a part.
2.
Press [CURSOR] to move the cursor to the following
location.
fig.PatchType
3.
Use the VALUE dial or [INC] [DEC] to select “RHY.”
The rhythm set will be selected.
fig.PatchType2
Using the PATCH SELECT screen
1.
Select the part whose sound you want to switch.
2.
Press [PATCH SELECT].
The PATCH SELECT screen appears.
fig.PatchSelectPfm
3.
To select a rhythm set, press [F5 (RHYTHM)] to add a check
mark (
✔
).
If you add a mark, the RHYTHM SELECT screen appears.
4.
Press [F1] or [F2] to select a group.
5.
Use [F3], [F4], PART/TRACK [1]–[8], [INC] [DEC], ,
or the VALUE dial to select a patch/rhythm set.
6.
Press [ENTER] to return to the PERFORM LAYER screen.
In the PERFORM MIXER screen you can set the following
parameters for each part.
1.
Press [MIXER].
The PERFORM MIXER screen appears.
2.
Press [F1 (LEVEL)]–[F6 (PART-OUT)] to select the
parameter.
3.
Press [CURSOR] to select the part.
fig.PartEdit
4.
Use the VALUE dial or [INC] [DEC] to change the setting.
Using the MIXER Screen
Selecting a Part
Selecting the Sound for a Part
Editing the Part Settings
Parameter
(Function Button)
Explanation
[F1 (LEVEL)]
Volume of each part (Level, p. 73)
[F2 (PAN)] Left/right position of each part
(Pan, p. 73)
[F3 (CHORUS)] Level of the signal sent to chorus
for each part (Chorus, p. 74)
[F4 (REVERB)] Level of the signal sent to reverb for
each part (Reverb, p. 74)
[F5 (KEY SFT)] Pitch of the part’s sound (in semi-
tones, +/-4 octaves) (Coarse, p. 74)
[F6 (PART-OUT)] KBD Keyboard Switch (p. 68)
PAD Pad Part (p. 117)
ARP Arpeggio Part (p. 88)
OUT Output Assign (Asgn, p. 74)
