226 Appendix A: Parameter Lists
02R96—Owner’s Manual
DELAY LCR
One input, two output 3-tap delay (left, center, right).
Parameter Range Description
DELAY L
0.0–2730.0 ms Left channel delay time
DELAY C
0.0–2730.0 ms Center channel delay time
DELAY R
0.0–2730.0 ms Right channel delay time
FB. DLY
0.0–2730.0 ms Feedback delay time
LEVEL L
–100 to +100% Left channel delay level
LEVEL C
–100 to +100% Center channel delay level
LEVEL R
–100 to +100% Right channel delay level
FB. GAIN
–99 to +99%
Feedback gain (plus values for normal-phase feedback,
minus values for reverse-phase feedback)
HI. RATIO
0.1–1.0 High-frequency feedback ratio
HPF
THRU, 21.2 Hz–8.00
kHz
High-pass filter cutoff frequency
LPF
50.0 Hz–16.0 kHz,
THRU
Low-pass filter cutoff frequency
SYNC
OFF/ON Tempo parameter sync on/off
NOTE L
1
1. (Maximum value depends on
the tempo setting)
Used in conjunction with TEMPO to determine DELAY L
NOTE C
1
Used in conjunction with TEMPO to determine DELAY C
NOTE R
1
Used in conjunction with TEMPO to determine DELAY R
NOTE FB
1
Used in conjunction with TEMPO to determine FB. DLY
