Effects Parameters 239
02R96—Owner’s Manual
DELAY+ER.
One input, two output delay and early reflections effects in parallel.
Parameter Range Description
DELAY L
0.0–1000.0 ms Left channel delay time
DELAY R
0.0–1000.0 ms Right channel delay time
FB. DLY
0.0–1000.0 ms Feedback delay time
FB. GAIN
–99 to +99%
Feedback gain (plus values for normal-phase feedback,
minus values for reverse-phase feedback)
HI. RATIO
0.1–1.0 High-frequency feedback ratio
HPF
THRU, 21.2 Hz–8.00
kHz
High-pass filter cutoff frequency
LPF
50.0 Hz–16.0 kHz,
THRU
Low-pass filter cutoff frequency
DLY/ER
0–100%
Delay and early reflections balance (0% = all delay, 100% =
all early reflections)
TYPE
S-Hall, L-Hall, Random,
Revers, Plate, Spring
Type of early reflection simulation
ROOMSIZE
0.1–20.0 Reflection spacing
LIVENESS
0–10 Early reflections decay characteristics (0 = dead, 10 = live)
INI. DLY
0.0–500.0 ms Initial delay before reverb begins
DIFF.
0.1–1.0 Spread
DENSITY
0–100% Reverb density
ER NUM.
1–19 Number of early reflections
SYNC
OFF/ON Tempo parameter sync on/off
NOTE L
1
1. (Maximum value depends on
the tempo setting)
Used in conjunction with TEMPO to determine left channel
DELAY L
NOTE R
1
Used in conjunction with TEMPO to determine right chan-
nel DELAY R
NOTE FB
1
Used in conjunction with TEMPO to determine FB. DLY
