Panel Descriptions
Front Panel
fig.00-041
1. Display
A variety of information about the GS-10 appears here.
Normally, patch names are displayed.
2. PREAMP/SPEAKER (p. 21, p. 28)
(Preamp/Speaker Simulator)
GAIN Knob
Adjusts the degree of preamp distortion.
BASS Knob
Adjusts the sound quality of the preamp’s low-
frequency range.
MIDDLE Knob
Adjusts the sound quality of the preamp’s midrange.
TREBLE Knob
Adjusts the sound quality of the preamp’s high-
frequency range.
PRESENCE Knob
Adjusts the sound quality in the preamp’s ultra-high-
frequency range.
LEVEL Knob
Adjusts the preamp volume level.
PREAMP/SPEAKER On/Off Button
Press to change the settings.
CHANNEL SELECT Button
Switches the preamp channel.
3. COMP (Compressor) (p. 21, p. 31)
SUSTAIN Knob
Adjusts the compressor’s sustain effect (an effect that
keeps the sound playing).
COMP On/Off Button
Press to change the settings.
4. OD/DS (p. 21, p. 32)
(Overdrive/Distortion)
DRIVE Knob
Adjusts the degree of overdrive or distortion.
LEVEL Knob
Adjusts the overdrive/distortion volume level.
OD/DS On/Off Button
Press to change the settings.
5. DELAY (p. 21, p. 33)
FEEDBACK Knob
Adjusts the number of times the delay is repeated.
LEVEL Knob
Adjusts the volume level of the delay sound.
DELAY On/Off Button
Press to change the settings.
1
15
2
3 4 5 6 7
8
9
16
22
27 28
10
17
11
12
13 14
25
18
19
23
20
24
21
26
