Appendices
01 : Rack 160D
02 : Vtg Rack U
** ** 00 17 00 00 00 01 00 - 64 LM :Attack 0 - 100
** ** 00 18 00 00 00 01 00 - 64 LM :Threshold 0 - 100
** ** 00 19 00 00 00 01 00 - 11 LM :Ratio *Refer to "Table Ratio"
** ** 00 1A 00 00 00 01 00 - 64 LM :Release 0 - 100
** ** 00 1B 00 00 00 01 00 - 64 LM :Level 0 - 100
** ** 00 1C 00 00 00 01 00 - 64 ENH:Sensitivity 0 - 100
** ** 00 1D 00 00 00 01 00 - 0B ENH:Frequency *Refer to "Table ENH Frequency"
** ** 00 1E 00 00 00 01 00 - 64 ENH:Mix Level 0 - 100
** ** 00 1F 00 00 00 01 00 - 64 SG :Sensitivity 0 - 100
** ** 00 20 00 00 00 01 00 - 64 SG :Rise Time 0 - 100
** ** 00 21 00 00 00 01 00 - 64 TR :Wave Shape 0 - 100
** ** 00 22 00 00 00 01 00 - 71 TR :Rate *Refer to "Table Rate"
** ** 00 23 00 00 00 01 00 - 64 TR :Depth 0 - 100
** ** 00 24 00 00 00 01 00 - 64 DF :Tone -50 - +50
** ** 00 25 00 00 00 01 00 - 64 DF :Sensitivity 0 - 100
** ** 00 26 00 00 00 01 00 - 64 DF :Attack 0 - 100
** ** 00 27 00 00 00 01 00 - 64 DF :Depth 0 - 100
** ** 00 28 00 00 00 01 00 - 64 DF :Resonance 0 - 100
** ** 00 29 00 00 00 01 00 - 64 DF :Effect Level 0 - 100
** ** 00 2A 00 00 00 01 00 - 64 DF :Direct Level 0 - 100
** ** 00 2B 00 00 00 01 00 - 01 RM :Mode 00 : Normal
01 : Intelligent
** ** 00 2C 00 00 00 01 00 - 64 RM :Frequency 0 - 100
** ** 00 2D 00 00 00 01 00 - 64 RM :Effect Level 0 - 100
** ** 00 2E 00 00 00 01 00 - 64 RM :Direct Level 0 - 100
** ** 00 2F 00 00 00 01 00 - 01 FB :Mode 00 : OSC
01 : Natural
** ** 00 30 00 00 00 01 00 - 64 FB :Rise Time 0 - 100 Mode=OSC
** ** 00 31 00 00 00 01 00 - 64 FB :Rise Time(▲)
0 - 100 Mode=OSC
** ** 00 32 00 00 00 01 00 - 64 FB :F.B.Level 0 - 100
** ** 00 33 00 00 00 01 00 - 64 FB :F.B.Level(▲)
0 - 100 Mode=OSC
** ** 00 34 00 00 00 01 00 - 71 FB :Vibrato Rate 0 - 100 Mode=OSC *Refer to "Table Rate"
** ** 00 35 00 00 00 01 00 - 64 FB :Vibrato Depth 0 - 100 Mode=OSC
--- COMP ---
** ** 01 00 00 00 00 01 00 - 01 CS :On/Off 00 : Off
01 : On
** ** 01 01 00 00 00 01 00 - 64 CS :Sustain 0 - 100
** ** 01 02 00 00 00 01 00 - 64 CS :Level 0 - 100
--- OD/DS ---
** ** 02 00 00 00 00 01 00 - 01 OD :On/Off 00 : Off
01 : On
** ** 02 01 00 00 00 01 00 - 18 OD :Type *Refer to "Table OD Type"
** ** 02 02 00 00 00 01 00 - 64 OD :Drive 0 - 100
** ** 02 03 00 00 00 01 00 - 64 OD :Bass -50 - +50
** ** 02 04 00 00 00 01 00 - 64 OD :Treble -50 - +50
** ** 02 05 00 00 00 01 00 - 64 OD :Effect Level 0 - 100
** ** 02 06 00 00 00 01 00 - 64 OD :Direct Level 0 - 100
--- PREAMP/SP SIM ---
** ** 03 00 00 00 00 01 00 - 01 PRE/SP:On/Off 00 : Off
01 : On
** ** 03 01 00 00 00 02 00 - 02 PRE/SP:Channel Select A, B, C
** ** 03 02 00 00 00 01 00 - 2F PRE/SP:Type (Ach) *Refer to "Table PRE/SP Type"
** ** 03 03 00 00 00 01 00 - 78 PRE/SP:Gain (Ach) 0 - 120
** ** 03 04 00 00 00 01 00 - 64 PRE/SP:Bass (Ach) 0 - 100
** ** 03 05 00 00 00 01 00 - 64 PRE/SP:Middle (Ach) 0 - 100
** ** 03 06 00 00 00 01 00 - 64 PRE/SP:Treble (Ach) 0 - 100
** ** 03 07 00 00 00 01 00 - 64 PRE/SP:Presence (Ach) 0 - 100 (-100 - 0)
** ** 03 08 00 00 00 01 00 - 64 PRE/SP:Amp Level (Ach) 0 - 100
** ** 03 09 00 00 00 01 00 - 01 PRE/SP:Bright (Ach) 00 : Off
01 : On
** ** 03 0A 00 00 00 01 00 - 02 PRE/SP:Gain SW (Ach) 00 : Low
01 : Middle
02 : High
** ** 03 0B 00 00 00 01 00 - 0E PRE/SP:Speaker Type (Ach) 00 : OFF
01 : ORIGINAL
02 : 1x8"
03 : 1x10"
04 : 1x12"
05 : 1x15"
06 : 1x18"
07 : 2x12"
08 : 2x15"
09 : 4x10"
0A : 4x12"
0B : 8x10"
0C : 8x12"
0D : Custom1
0E : Custom2
** ** 03 0C 00 00 00 01 00 - 04 PRE/SP:Mic Type (Ach) 00 : DYN57
01 : DYN421
02 : CND451
03 : CND87
04 : FLAT
** ** 03 0D 00 00 00 01 00 - 01 PRE/SP:Mic Distance (Ach) 00 : Off Mic
01 : On Mic
** ** 03 0E 00 00 00 01 00 - 0A PRE/SP:Mic Position (Ach) 00 : Center
01 : 1
02 : 2
03 : 3
04 : 4
05 : 5
06 : 6
07 : 7
08 : 8
09 : 9
0A : 10
** ** 03 0F 00 00 00 01 00 - 64 PRE/SP:Mic Level (Ach) 0 - 100
** ** 03 10 00 00 00 01 00 - 64 PRE/SP:Direct Level (Ach) 0 - 100
** ** 03 11 00 00 00 01 00 - 2F PRE/SP:Type (Bch)
** ** 03 12 00 00 00 01 00 - 78 PRE/SP:Gain (Bch)
** ** 03 13 00 00 00 01 00 - 64 PRE/SP:Bass (Bch)
** ** 03 14 00 00 00 01 00 - 64 PRE/SP:Middle (Bch)
** ** 03 15 00 00 00 01 00 - 64 PRE/SP:Treble (Bch)
** ** 03 16 00 00 00 01 00 - 64 PRE/SP:Presence (Bch)
** ** 03 17 00 00 00 01 00 - 64 PRE/SP:Amp Level (Bch)
