Appendices
Appendices
--- FX-2 ---
** ** 05 00 00 00 00 01 20 - 7F Name 1 *Refer to "Table Name"
** ** 05 01# 00 00 00 01 20 - 7F Name 2
** ** : : : : :
** ** 05 0B# 00 00 00 01 20 - 7F Name 12
--- DELAY ---
** ** 06 00 00 00 00 01 20 - 7F Name 1 *Refer to "Table Name"
** ** 06 01# 00 00 00 01 20 - 7F Name 2
** ** : : : : :
** ** 06 0B# 00 00 00 01 20 - 7F Name 12
--- CHORUS ---
** ** 07 00 00 00 00 01 20 - 7F Name 1 *Refer to "Table Name"
** ** 07 01# 00 00 00 01 20 - 7F Name 2
** ** : : : : :
** ** 07 0B# 00 00 00 01 20 - 7F Name 12
--- REVERB ---
** ** 08 00 00 00 00 01 20 - 7F Name 1 *Refer to "Table Name"
** ** 08 01# 00 00 00 01 20 - 7F Name 2
** ** : : : : :
** ** 08 0B# 00 00 00 01 20 - 7F Name 12
--- ASSIGN ---
** ** 09 00 00 00 00 01 20 - 7F Name 1 *Refer to "Table Name"
** ** 09 01# 00 00 00 01 20 - 7F Name 2
** ** : : : : :
** ** 09 0B# 00 00 00 01 20 - 7F Name 12
Table Patch <Patch>
--------------------------------------------------------------------------------------------------------------
Address(H) Size(H) Data(H) Parameter Description
--------------------------------------------------------------------------------------------------------------
06 00 ** ** Patch 001 (User Patch)
06 01 ** ** Patch 002 (User Patch)
: :
06 63 ** ** Patch 100 (User Patch)
07 00 ** ** Patch 101 (Preset Patch)
: :
07 63 ** ** Patch 200 (Preset Patch)
08 00 ** ** Temporary Buffer (Bulk)
09 00 ** ** Temporary Buffer (Individual)
↑ ↑
↑ ↑
↑ ↑
↑ ↑
↑ ↑
--- FX-1 ---
** ** 00 00 00 00 00 01 00 - 01 FX1:On/Off 00 : Off
01 : On
** ** 00 01 00 00 00 01 00 - 0A FX1:FX Select 00 : PW
01 : AW
02 : TM
03 : ACS
04 : LM
05 : ENH
06 : SG
07 : TR
08 : DF
09 : RM
0A : FB
** ** 00 02 00 00 00 01 00 - 09 PW :Type 00 : CRY WAH
01 : VO WAH
02 : Fat WAH
03 : Light WAH
04 : 7String WAH
05 : Resonance WAH
06 : Bass WAH
07 : Custom1
08 : Custom2
09 : Custom3
** ** 00 03 00 00 00 01 00 - 64 PW :Pdl Position 0 - 100
** ** 00 04 00 00 00 01 00 - 64 PW :Level 0 - 100
** ** 00 05 00 00 00 01 00 - 01 AW :Mode 00 : LPF
01 : BPF
** ** 00 06 00 00 00 01 00 - 01 AW :Polarity 00 : Down
01 : Up
** ** 00 07 00 00 00 01 00 - 64 AW :Sensitivity 0 - 100
** ** 00 08 00 00 00 01 00 - 64 AW :Frequency 0 - 100
** ** 00 09 00 00 00 01 00 - 64 AW :Peak 0 - 100
** ** 00 0A 00 00 00 01 00 - 71 AW :Rate *Refer to "Table Rate"
** ** 00 0B 00 00 00 01 00 - 64 AW :Depth 0 - 100
** ** 00 0C 00 00 00 01 00 - 64 AW :Level 0 - 100
** ** 00 0D 00 00 00 01 00 - 0C TM :Type 00 : Fat
01 : Presence
02 : Mild
03 : Tight
04 : Enhance
05 : 'S' to 'H'
06 : 'H' to 'S'
07 : 'H' to 'HF'
08 : 'S' to Hollow
09 : 'H' to Hollow
0A : 'S' to Acoustic
0B : 'H' to Acoustic
0C : 'P' to Acoustic
** ** 00 0E 00 00 00 01 00 - 64 TM :Low -50 - +50
** ** 00 0F 00 00 00 01 00 - 64 TM :High -50 - +50
** ** 00 10 00 00 00 01 00 - 64 TM :Level 0 - 100
** ** 00 11 00 00 00 01 00 - 02 ACS:Type 00 : Stereo Comp
01 : BOSS Comp
02 : D-Comp
** ** 00 12 00 00 00 01 00 - 64 ACS:Sustain 0 - 100
** ** 00 13 00 00 00 01 00 - 64 ACS:Attack 0 - 100
** ** 00 14 00 00 00 01 00 - 64 ACS:Tone -50 - +50
** ** 00 15 00 00 00 01 00 - 64 ACS:Level 0 - 100
** ** 00 16 00 00 00 01 00 - 02 LM :Type 00 : Stereo Limiter
