Roland SC-88 Pro Musical Instrument User Manual



Connecting another MIDI sound source to the unit
If you wish to connect another MIDI sound source to this unit's MIDI OUT/THRU con-
nector, be aware of the following points.
When using another sound source to play data received at the computer connector
In this situation, set MIDI OUT/THRU Select (p.136) to OUT. Computer data received
at the computer connector will be transmitted from this unit MIDI OUT/THRU connector.
When using another sound source to play data received at MIDI IN A
In this situation, set MIDI OUT/THRU Select (p.136) to THRU. Data received at MIDI
IN A will be transmitted just as it is from MIDI OUT/THRU.
* Data received at MIDI IN B will not be passed THRU even if THRU is selected. Regardless of
the Input Mode setting (In mode p.137), data from MIDI IN B will not be THRUed.
MIDI IN B
(Front)
MIDI IN B
(Rear)
MIDI IN A
COMPUTER
MIDI
OUT/THRU
Part group A
GM/GS
Sound generator
Part A1 - A16
Part group B
GM/GS
Sound generator
Part B1 - B16
MIDI Sound
Module
MIDI OUT
MIDI IN
MIDI keyboard
This unit
MIDI OUT/THRU selection : OUT
MIDI IN B
(Front)
MIDI IN B
(Rear)
MIDI IN A
COMPUTER
MIDI
OUT/THRU
Part group A
GM/GS
Sound generator
Part A1 - A16
Part group B
GM/GS
Sound generator
Part B1 - B16
MIDI Sound
Module
MIDI OUT
MIDI IN
MIDI keyboard
This unit
MIDI OUT/THRU selection : THRU
Chapter 6. Using the unit with a personal computer
125
