Chapter 8. Appendix
178
Parameter Value (Dec.)
Value (Hex.) min - max
MSB/LSB(H)
# Balance D> 0E - D>74E - D 0<E 00 - 7F 12
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
Level 0 - 127 00 - 7F 16
25 : Tm Ctrl Delay 01 54
+ Dly Time 200m - 500m - 990m/1sec*3 03
Accel 0 - 10 - 15 *14 04
# Feedback -98% - +32% - +98% 0F - 71 05
HF Damp 315 - 8k/Bypass *8 06
EFX Pan L63 - 0 - R63 00 - 7F 07
Balance D> 0E - D>74E - D 0<E 00 - 7F 12
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
Level 0 - 127 00 - 7F 16
26 : Reverb 01 55
Type Room1/2/Stage1/2/Hall1/2 00/01/02/03/04/05 03
Pre Dly 0 - 74m - 100m *1 04
+ Time 0 - 120 - 127 00 - 7F 05
HF Damp 315 - 6.3k - 8k/Bypass *8 06
# Balance D> 0E - D=E - D 0<E 00 - 7F 12
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
Level 0 - 127 00 - 7F 16
27 : Gate Reverb 01 56
Type Norm/Reverse/Sweep1/2 00/01/02/03 03
Pre Dly 0 - 0.5m - 100m *1 04
Gate Time 0 - 65m - 500m 00 - 63 05
+ Balance D> 0E - D>65E - D 0<E 00 - 7F 12
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - -3 - +12 34 - 4C 14
# Level 0 - 112 - 127 00 - 7F 16
28 : 3D Delay 01 57
Dly Tm C 0m - 300m - 500m *4 03
Dly Tm L 0m - 200m - 500m *4 04
Dly Tm R 0m - 240m - 500m *4 05
+ Feedback -98% - +32% - +98% 0F - 71 06
Dly Lev C 0 - 40 - 127 00 - 7F 07
Dly Lev L 0 - 64 - 127 00 - 7F 08
Dly Lev R 0 - 64 - 127 00 - 7F 09
HF Damp 315 - 8k/Bypass *8 0A
Out Speaker/Phones 00/01 11
# Balance D> 0E - D>74E - D 0<E 00 - 7F 12
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
Level 0 - 127 00 - 7F 16
❍ Effects that modify the pitch (pitch/shift type)
29 : 2 Pitch Shifter 01 60
+ Coarse 1 -24 - +7 - +12 28 - 4C 03
Fine 1 -100 - -4 - +100 0E - 72 04
Pre Dly 1 0 - 100m *1 05
EFX Pan 1 L63 - 0 - R63 00 - 7F 06
# Coarse 2 -24 - -5 - +12 28 - 4C 07
Fine 2 -100 - +4 - +100 0E - 72 08
Pre Dly 2 0 - 100m *1 09
EFX Pan 2 L63 - 0 - R63 00 - 7F 0A
Shift Mode 1 - 3 - 5 00 - 04 0B
L.Bal A> 0B - A=B - A 0<B 00 - 7F 0C
Balance D> 0E - D>74E - D 0<E 00 - 7F 12
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
Level 0 - 95 - 127 00 - 7F 16
Parameter Value (Dec.)
Value (Hex.) min - max
MSB/LSB(H)
30 : Fb P.Shifter 01 61
+ P.Coarse -24 - +7 - +12 28 - 4C 03
P.Fine -100 - 0 - +100 0E - 72 04
# Feedback -98% - +40% - +98% 0F - 71 05
Pre Dly 0 - 45m - 100m *1 06
Mode 1 - 3 - 5 00 - 04 07
EFX Pan L63 - 0 - R63 00 - 7F 08
Balance D> 0E - D=E - D 0<E 00 - 7F 12
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - -6 - +12 34 - 4C 14
Level 0 - 127 00 - 7F 16
❍ Others
31 : 3D Auto 01 70
Azimuth 180/L168 - 0 - R168 *13 03
+ Speed 0.05 - 1.30 - 10.0 *6 04
Clockwise -/+ 00/01 05
# Turn Off/On 00/01 06
Out Speaker/Phones 00/01 11
Level 0 - 127 00 - 7F 16
32 : 3D Manual 01 71
+ Azimuth 180/L168 - 0 - R168 *13 03
Out Speaker/Phones 00/01 11
# Level 0 - 127 00 - 7F 16
33 : Lo-Fi 1 01 72
Pre Filter 1 - 2 - 6 00 - 05 03
Lo-Fi Type 1 - 6 - 9 00 - 08 04
Post Filter 1 - 2 - 6 00 - 05 05
+ Balance D> 0E - D 0<E 00 - 7F 12
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
# Pan L63 - 0 - R63 00 - 7F 15
Level 0 - 127 00 - 7F 16
34 : Lo-Fi 2 01 73
Lo-Fi Type 1 - 2 - 6 00 - 05 03
Fil Type Off/LPF/HPF 00/01/02 04
Cutoff 250 - 630 - 8k *9 05
+ R.Detune 0 - 127 00 - 7F 06
R.Nz Lev 0 - 64 - 127 00 - 7F 07
W/P Sel White/Pink 00/01 08
W/P LPF 250 - 6.3k/Bypass *11 09
W/P Level 0 - 127 00 - 7F 0A
Disc Type LP/EP/SP/RND 00/01/02/03 0B
Disc LPF 250 - 6.3k/Bypass *11 0C
Disc Nz Lev 0 - 127 00 - 7F 0D
Hum Type 50Hz/60Hz 00/01 0E
Hum LPF 250 - 6.3k/Bypass *11 0F
Hum Level 0 - 127 00 - 7F 10
M/S Mono/Stereo 00 - 01 11
# Balance D> 0E - D 0<E 00 - 7F 12
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
Pan(Mono) L63 - 0 - R63 00 - 7F 15
Level 0 - 127 00 - 7F 16
+: Effect control 1 can be used to modify the value (p.92)
#: Effect control 2 can be used to modify the value (p.92)
MSB/LSB: Indicates the ** portion of the following exclusive mes-
sages. (p.196) (hexadecimal notation)
For Effect Type (data section)
F0 41 dev 42 12 40 03 00 ** ** sum F7
For Effect Parameters (LSB part of address)
F0 41 dev 42 12 40 03 ** data sum F7
(dev: device ID, sum: checksum)
The correspondence between setting values and hexadeci-
mal values for items in the Value column indicated with "*" is
shown in the "Effect Data Table" (p. 183).
*1 Pre Delay Time *8 HF Damp
*2 Delay Time 1 *9 Cutoff Freq
*3 Delay Time 2 *10 EQ Freq
*4 Delay Time 3 *11 LPF
*5 Delay Time 4 *12 Manual
*6 Rate 1 *13 Azimuth
*7 Rate 2 *14 Accl
