Chapter 8. Appendix
206
■ Dumping a list of internal sounds
● Instrument list dump
❍ Instrument list dump request (request only) [Pro]
This command requests a bulk dump of a list of the preset sounds (Instruments) in
internal memory, and uses "Data Request 1 (RQ1)" format. The Size specifies the
contents of the requested data.
Address: 0C 00 01
Size: 00 00 00 : ALL
00 00 01 : SC-55 MAP
00 00 02 : SC-88 MAP
00 00 03 : Native MAP
00 mm bb mm = MAP# 01 - 03 ( 01 = SC-55 MAP, 02 = SC-88 MAP,
03 = Native MAP)
bb = BANK# 00 - 7F
❍ Instrument list dump (transmit only) [Pro]
When Instrument List Dump Request is received, the sound names of the specified
map will be transmitted continuously in the format given below, where 16 bytes are
used for each sound name. The Address of the transmitted data is 0C 00 01 for all
packets.User bank sound names are not transmitted.
DUMP FORMAT:
CC0 : Variation number
MAP : MAP number 01 = SC-55 MAP, 02 = SC-88 MAP, 03 = Native MAP
PC : Program number
● Drum set list dump
❍ Drum set list dump request (receive only) [Pro]
This command requests a bulk dump transmission of a list of Preset Drum Sets in
internal memory, and uses "Data Request 1 (RQ1)" format. The Size specifies the
desired data contents.
Address: 0C 00 02
Size: 00 00 00 : ALL
00 00 01 : SC-55 MAP
00 00 02 : SC-88 MAP
00 00 03 : Native MAP
❍ Drum set list dump (transmit only) [Pro]
When a Drum Set List Dump Request is received, the Drum Set names of the speci-
fied MAP will be transmitted successively in the format given below, where 16 bytes
are used for each sound. The Address of the transmitted data will be 0C 00 02 for
each packet.
DUMP FORMAT:
MAP : MAP number 01 = SC-55 MAP, 02 = SC-88 MAP, 03 = Native MAP
PC : Program number
● Drum instrument list dump
❍ Drum instrument list dump request (receive only) [Pro]
This command requests a bulk dump transmission of the Instrument list of an inter-
nal Preset Drum Sets, and uses "Data Request 1 (RQ1)" format. The Size specifies
the desired data contents.
Address: 0C 00 03
Size: 00 mm pp mm = MAP# 01 - 03 ( 01 = SC-55 MAP, 02 = SC-88 MAP,
03 = Native MAP)
pp = Drum set# 00 - 7F (same as PC#)
❍ Drum instrument list dump (transmit only) [Pro]
When a Drum Instrument List Dump Request is received, the Drum Instrument
names of the specified Drum Set will be transmitted in the following format where 16
bytes are used for each Drum Instrument name. The address of the transmitted data
will be 0C 00 03 for each packet.
DUMP FORMAT:
MAP : MAP number 01 = SC-55 MAP, 02 = SC-88 MAP, 03 = Native MAP
PC : Program number
KEY : Note number
● Insertion effect list dump
❍ Insertion effect list dump request (receive only) [Pro]
This command requests a bulk dump transmission of the Insertion effect list of an
internal memory, and uses "Data Request 1 (RQ1)" format. The Size specifies the
desired data contents.
Address: 0C 00 04
Size: 00 00 00 : ALL
❍ Insertion effect list dump (transmit only) [Pro]
When a Insertion Effect List Dump Request is received, the specified Insertion Effect
names will be transmitted in the following format where 20 bytes are used for each
Effect name. The address of the transmitted data will be 0C 00 04 for each packet.
DUMP FORMAT :
MSB : Category
LSB : Type
● Preset patch list dump
❍ Preset patch list dump request (receive only) [Pro]
This command requests a bulk dump transmission of the Preset patch list of an
internal memory, and uses "Data Request 1 (RQ1)" format. The Size specifies the
desired data contents.
Address: 0C 00 05
Size: 00 00 00 : ALL
❍ Preset patch list dump (transmit only) [Pro]
When a Preset Patch List Dump Request is received, the specified Preset patch
names will be transmitted in the following format where 20 bytes are used for each
Patch name. The address of the transmitted data will be 0C 00 05 for each packet.
DUMP FORMAT :
PC : Program number
0123 54 6789ABCDEF
CC0 MAP PC 00 TONE NAME(ASCII 12 Characters)
0123 54 6789ABCDEF
00 MAP PC 00 DRUM TONE NAME(ASCII 12 Characters)
0123 54 6789ABCDEF
00 MAP PC KEY DRUM TONE NAME(ASCII 12 Characters)
0123 54 6789ABCDEF
MSB LSB 00 00 EFFECT NAME(ASCII 16 Characters)
10 11 12 13
0123 54 6789ABCDEF
00 00 PC 00 PATCH NAME(ASCII 16 Characters)
10 11 12 13
