Chapter 8. Appendix
195
Address(H) Size(H) Data(H) Parameter Description Default Value (H) Description
40 01 38 00 00 01 00 - 07 CHORUS MACRO 00: Chorus 1 02 Chorus 3
01: Chorus 2
02: Chorus 3
03: Chorus 4
04: Feedback Chorus
05: Flanger
06: Short Delay
07: Short Delay(FB)
40 01 39 00 00 01 00 - 07 CHORUS PRE-LPF 0-7 00 0
40 01 3A 00 00 01 00 - 7F CHORUS LEVEL 0-127 40 64
40 01 3B 00 00 01 00 - 7F CHORUS FEEDBACK 0-127 08 8
40 01 3C 00 00 01 00 - 7F CHORUS DELAY 0-127 50 80
40 01 3D 00 00 01 00 - 7F CHORUS RATE 0-127 03 3
40 01 3E 00 00 01 00 - 7F CHORUS DEPTH 0-127 13 19
40 01 3F 00 00 01 00 - 7F CHORUS SEND LEVEL TO REVERB 0-127 00 0
40 01 40 00 00 01 00 - 7F CHORUS SEND LEVEL TO DELAY[88] 0-127 00 0
* CHORUS MACRO is a macro parameter that allows global setting of chorus parameters. When you use CHORUS MACRO to select the chorus type, each chorus parameter
will be set to the most suitable value.
* In MODE-2 (Double module mode), CHORUS SEND LEVEL TO DELAY cannot be used.
40 01 50 00 00 01 00 - 09 DELAY MACRO [88] 00: Delay 1 00 Delay1
01: Delay 2
02: Delay 3
03: Delay 4
04: Pan Delay 1
05: Pan Delay 2
06: Pan Delay 3
07: Pan Delay 4
08: Delay to Reverb
09: Pan Repeat
40 01 51 00 00 01 00 - 07 DELAY PRE-LPF [88] 0 - 7 00 0
40 01 52 00 00 01 01 - 73 DELAY TIME CENTER [88] 0.1ms - 1sec 61 340
40 01 53 00 00 01 01 - 78 DELAY TIME RATIO LEFT [88] 4 - 500% 01 4
40 01 54 00 00 01 01 - 78 DELAY TIME RATIO RIGHT [88] 4 - 500% 01 4
40 01 55 00 00 01 00 - 7F DELAY LEVEL CENTER [88] 0 - 127 7F 127
40 01 56 00 00 01 00 - 7F DELAY LEVEL LEFT [88] 0 - 127 00 0
40 01 57 00 00 01 00 - 7F DELAY LEVEL RIGHT [88] 0 - 127 00 0
40 01 58 00 00 01 00 - 7F DELAY LEVEL [88] 0 - 127 40 64
40 01 59 00 00 01 00 - 7F DELAY FEEDBACK [88] -64 - +63 50 +16
40 01 5A 00 00 01 00 - 7F DELAY SENDLEVEL TO REVERB[88] 0 - 127 00 0
* DELAY MACRO is a macro parameter that allows global setting of delay parameters. When you use DELAY MACRO to select the delay type, each delay parameter will be
set to the most suitable value.
* The relation between the DELAY TIME CENTER value and the actual delay time is as follows.
* DELAY TIME RATIO LEFT and DELAY TIME RATIO RIGHT specify the ratio in relation to DELAY TIME CENTER. The resolution is 100/24(%).
* In MODE-2 (Double module mode), Delay cannot be used.
40 02 00 00 00 01 00 - 01 EQ LOW FREQ. [88] 200Hz, 400Hz 00 200Hz
40 02 01 00 00 01 34 - 4C EQ LOW GAIN [88] -12 - +12dB 40 0
40 02 02 00 00 01 00 - 01 EQ HIGH FREQ. [88] 3kHz, 6kHz 00 3kHz
40 02 03 00 00 01 34 - 4C EQ HIGH GAIN [88] -12 - +12dB 40 0
* In MODE-2 (Double module mode), EQ (equalizer) cannot be used.
DELAY TIME Time Range[ms] Resolution[ms]
01 - 14 0.1 - 2.0 0.1
14 - 23 2.0 - 5.0 0.2
23 - 2D 5.0 - 10.0 0.5
2D - 37 10.0 - 20.0 1.0
37 - 46 20.0 - 50.0 2.0
DELAY TIME Time Range[ms] Resolution[ms]
46 - 50 50.0 - 100.0 5.0
50 - 5A 100.0 - 200.0 10.0
5A - 69 200.0 - 500.0 20.0
69 - 73 500.0 - 1000.0 50.0
