Controllers can be used to modify the values of Insertion effect parameters.
Using MIDI messages to modify effect parameters during a song would require a large
amount of data if you were to use only Exclusive messages. Thus, this unit allows you to
use controllers to set the main effect parameters. Since you can use Control Change
messages to modify parameter values, the amount of data will not be excessively large,
even if you modify parameter values during a song.
Also, if you are using a keyboard etc. to play, you can use controllers to modify the val-
ues in realtime.
EFX C.Src1, 2 (Effect Control Source 1, 2)
EFX C.Dep1, 2 (Effect Control Depth 1, 2)
● Setting procedure
1. Press [ALL] to make the button indicator light.
2. Simultaneously press PART [ll
ll
] and [rr
rr
].
3. Press either [uu
uu
] or [dd
dd
] to select the parameter whose setting you wish to
change.
You can skip parameters by pressing [u][d], while holding [SELECT].
4. Use INSTRUMENT [ll
ll
][rr
rr
] to set the value.
5. When you finish making settings, simultaneously press PART [ll
ll
] and
[rr
rr
] to end the procedure.
PART
INSTRUMENT
ALL
100 0
LEVEL
PAN
>EFX C.Src1: Off
INSTRUMENTPAR T
LEVEL
PA N
REVERB
CHORUS
KEY SHIFT
MIDI CH
DELAY
ALL
MUTE
SC
-
55
MAP
SC
-
88
MAP
2
3
4
5
1
Chapter 4. Insertion Effects
92
■ Using controllers to modify effect parameters
