Chapter 8. Appendix
197
40 1x 0B 00 00 01 00 - 01 Rx. MODULATION OFF / ON 01 ON
40 1x 0C 00 00 01 00 - 01 Rx. VOLUME OFF / ON 01 ON
40 1x 0D 00 00 01 00 - 01 Rx. PANPOT OFF / ON 01 ON
40 1x 0E 00 00 01 00 - 01 Rx. EXPRESSION OFF / ON 01 ON
40 1x 0F 00 00 01 00 - 01 Rx. HOLD1 OFF / ON 01 ON
40 1x 10 00 00 01 00 - 01 Rx. PORTAMENTO OFF / ON 01 ON
40 1x 11 00 00 01 00 - 01 Rx. SOSTENUTO OFF / ON 01 ON
40 1x 12 00 00 01 00 - 01 Rx. SOFT OFF / ON 01 ON
40 1x 13 00 00 01 00 - 01 MONO/POLY MODE Mono / Poly 01 Poly
(=CC# 126 01 / CC# 127 00)
40 1x 14 00 00 01 00 - 02 ASSIGN MODE 0 = SINGLE SC-88/Native MAP
1 = LIMITED-MULTI 01 LIMITED-MULTI
2 = FULL-MULTI SC-55 MAP
00 at x=0 SINGLE (Drum Part)
01 at x≠0 LIMITED-MULTI (Normal Part)
* ASSIGN MODE is the parameter that determines how voice assignment will be handled when sounds overlap on identical note numbers in the same channel (i.e., repeatedly
struck notes). This is initialized to a mode suitable for each Part, so for general purposes there is no need to change this.
40 1x 15 00 00 01 00 - 02 USE FOR RHYTHM PART 0 = OFF 00 at x≠0 OFF (Normal Part)
1 = MAP1 01 at x=0 MAP1 (Drum Part)
2 = MAP2
* This parameter sets the Drum Map of the Part used as the Drum Part. This unit can simultaneously (in different Parts) use up to two Drum Maps (MAP1, MAP2). With the ini-
tial settings, Part10 (MIDI CH=10, x=0) is set to MAP1 (1), and other Parts are set to normal instrumental Parts (OFF(0)).
Address(H) Size(H) Data(H) Parameter Description Default Value (H) Description
40 1x 16 00 00 01 28 - 58 PITCH KEY SHIFT -24 - +24 [semitones] 40 0 [semitones]
40 1x 17 00 00 02 08 - F8 PITCH OFFSET FINE -12.0 - +12.0 [Hz] 08 00 0 [Hz]
40 1x 18# Use nibblized data.
* PITCH OFFSET FINE allows you to alter, by a specified frequency amount, the pitch at which notes will sound. This parameter differs from the conventional Fine Tuning
(RPN #1) parameter in that the amount of frequency alteration (in Hertz) will be identical no matter which note is played. When a multiple number of Parts, each of which has
been given a different setting for PITCH OFFSET FINE, are sounded by means of an identical note number, you can obtain a Celeste effect.
40 1x 19 00 00 01 00 - 7F PART LEVEL 0 - 127 64 100
(=CC# 7)
40 1x 1A 00 00 01 00 - 7F VELOCITY SENSE DEPTH 0 - 127 40 64
40 1x 1B 00 00 01 00 - 7F VELOCITY SENSE OFFSET 0 - 127 40 64
40 1x 1C 00 00 01 00 - 7F PART PANPOT -64(RANDOM), 40 0 (CENTER)
-63(LEFT) - +63(RIGHT)
(=CC# 10, except RANDOM)
40 1x 1D 00 00 01 00 - 7F KEYBOARD RANGE LOW (C-1) - (G9) 00 C-1
40 1x 1E 00 00 01 00 - 7F KEYBOARD RANGE HIGH (C-1) - (G9) 7F G 9
40 1x 1F 00 00 01 00 - 5F CC1 CONTROLLER NUMBER 0 - 95 10 16
40 1x 20 00 00 01 00 - 5F CC2 CONTROLLER NUMBER 0 - 95 11 17
40 1x 21 00 00 01 00 - 7F CHORUS SEND LEVEL 0 - 127 00 0
(=CC# 93)
40 1x 22 00 00 01 00 - 7F REVERB SEND LEVEL 0 - 127 28 40
(=CC# 91)
40 1x 23 00 00 01 00 - 01 Rx.BANK SELECT OFF / ON 01(00*) ON(OFF*)
* When "General MIDI System On" is received, Rx.BANK SELECT will be set OFF. When "GS Reset" or "System Mode Set" is received, it will be set ON.
40 1x 24 00 00 01 00 - 01 RX BANK SELECT LSB [88] OFF / ON 01 ON
* When RX BANK SELECT LSB = OFF, Bank Select LSB (Bn 20 11) will be treated as 00H regardless of its value.
40 1x 2A 00 00 02 00 00 - 40 00 - 7F 7F PITCH FINE TUNE [88] -100 - 0 - +100 [cent] 40 00 0
(= RPN#1)
40 1x 2B#
40 1x 2C 00 00 01 00 - 7F DELAY SEND LEVEL [88] 0-127 00 0
(=CC# 94)
* In MODE-2 (Double module mode), DELAY SEND LEVEL cannot be used.
