Chapter 8. Appendix
180
Parameter Value (Dec.)
Value (Hex.) min - max
MSB/LSB(H)
46 : Cho→ Flanger 02 0B
Cho Dly 0 - 1.0m - 100m *1 03
Cho Rate 0.05 - 0.45 - 10.0 *6 04
Cho Depth 0 - 120 - 127 00 - 7F 05
+ Cho Bal D> 0E - D=E - D 0<E 00 - 7F 07
FL Dly 0 - 1.6m - 100m *1 08
FL Rate 0.05 - 0.60 - 10.0 *6 09
FL Depth 0 - 24 - 127 00 - 7F 0A
FL Fb -98% - +80% - +98% 0F - 71 0B
# FL Bal D> 0E - D=E - D 0<E 00 - 7F 0C
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
Level 0 - 112 - 127 00 - 7F 16
❍ Effects that connect three or more types of
effect in series (series 3 / series 4 / series 5)
47 : Rotary Multi 02 0C
+ OD Drive 0 - 13 - 127 00 - 7F 03
OD Sw Off/On 00/01 04
EQ L Gain -12 - 0 - +12 34 - 4C 05
EQ M Fq 200 - 1.6k - 6.3k *10 06
EQ M Q 0.5/1.0/2.0/4.0/9.0 00/01/02/03/04 07
EQ M Gain -12 - 0 - +12 34 - 4C 08
EQ H Gain -12 - 0 - +12 34 - 4C 09
RT L Slow 0.05 - 0.35 - 10.0 *6 0A
RT L Fast 0.05 - 6.40 - 10.0 *6 0B
RT Lo Accl 0 - 3 - 15 *14 0C
RT Lo Lev 0 - 127 00 - 7F 0D
RT H Slow 0.05 - 0.90 - 10.0 *6 0E
RT H Fast 0.05 - 7.50 - 10.0 *6 0F
RT Hi Accl 0 - 11 - 15 *14 10
RT Hi Lev 0 - 64 - 127 00 - 7F 11
RT Sept 0 - 96 - 127 00 - 7F 12
# RT Speed Slow/Fast 00/7F 13
Level 0 - 96 - 127 00 - 7F 16
48 : GTR Multi 1 04 00
Cmp Atck 0 - 100 - 127 00 - 7F 03
Cmp Sus 0 - 80 - 127 00 - 7F 04
Cmp Level 0 - 100 - 127 00 - 7F 05
Cmp Sw Off/On 00/01 06
OD Sel Odrv/Dist 00/01 07
+ OD Drive 0 - 80 - 127 00 - 7F 08
OD Amp Small/BltIn/2-Stk/3-Stk 00/01/02/03 09
OD Amp Sw Off/On 00/01 0A
OD L Gain -12 - +5 - +12 34 - 4C 0B
OD H Gain -12 - +10 - +12 34 - 4C 0C
OD Sw Off/On 00/01 0D
CF Sel Chorus/Flangr 00/01 0E
CF Rate 0.05 - 0.45 - 6.40 *7 0F
CF Depth 0 - 30 - 127 00 - 7F 10
CF Fb -98% - +76% - +98% 0F - 71 11
CF Mix 0 - 40 - 127 00 - 7F 12
Dly Time 0m - 300m - 635m *5 13
Dly Fb 0 - 34 - 127 00 - 7F 14
# Dly Mix 0 - 15 - 127 00 - 7F 15
Level 0 - 110 - 127 00 - 7F 16
49 : GTR Multi 2 04 01
Cmp Atck 0 - 70 - 127 00 - 7F 03
Cmp Sus 0 - 127 00 - 7F 04
Cmp Level 0 - 90 - 127 00 - 7F 05
Cmp Sw Off/On 00/01 06
Parameter Value (Dec.)
Value (Hex.) min - max
MSB/LSB(H)
OD Sel Odrv/Dist 00/01 07
+ OD Drive 0 - 80 - 127 00 - 7F 08
OD Amp Small/BltIn/2-Stk/3-Stk 00/01/02/03 09
OD Amp Sw Off/On 00/01 0A
OD Sw Off/On 00/01 0B
EQ L Gain -12 - +12 34 - 4C 0C
EQ M Fq 200 - 1k - 6.3k *10 0D
EQ M Q 0.5/1.0/2.0/4.0/9.0 00/01/02/03/04 0E
EQ M Gain -12 - +5 - +12 34 - 4C 0F
EQ H Gain -12 - -10 - +12 34 - 4C 10
CF Sel Chorus/Flangr 00/01 11
CF Rate 0.05 - 0.45 - 6.40 *7 12
CF Depth 0 - 96 - 127 00 - 7F 13
CF Fb -98% - +76% - +98% 0F - 71 14
# CF Mix 0 - 127 00 - 7F 15
Level 0 - 80 - 127 00 - 7F 16
50 : GTR Multi 3 04 02
Wah Fil LPF/BPF 00/01 03
+ Wah Man 0 - 60 - 127 00 - 7F 04
Wah Peak 0 - 10 - 127 00 - 7F 05
Wah Sw Off/On 00/01 06
OD Sel Odrv/Dist 00/01 07
# OD Drive 0 - 80 - 127 00 - 7F 08
OD Amp Small/BltIn/2-Stk/3-Stk 00/01/02/03 09
OD Amp Sw Off/On 00/01 0A
OD L Gain -12 - 0 - +12 34 - 4C 0B
OD H Gain -12 - 0 - +12 34 - 4C 0C
OD Sw Off/On 00/01 0D
CF Sel Chorus/Flangr 00/01 0E
CF Rate 0.05 - 0.45 - 6.40 *7 0F
CF Depth 0 - 127 00 - 7F 10
CF Fb -98% - +50% - +98% 0F - 71 11
CF Mix 0 - 50 - 127 00 - 7F 12
Dly Time 0m - 160m - 635m *5 13
Dly Fb 0 - 64 - 127 00 - 7F 14
Dly Mix 0 - 30 - 127 00 - 7F 15
Level 0 - 88 - 127 00 - 7F 16
51 : Clean Gt Multi1 04 03
Cmp Atck 0 - 50 - 127 00 - 7F 03
Cmp Sus 0 - 127 00 - 7F 04
Cmp Level 0 - 75 - 127 00 - 7F 05
Cmp Sw Off/On 00/01 06
EQ L Gain -12 - +12 34 - 4C 07
EQ M Fq 200 - 6.3k *10 08
EQ M Q 0.5/1.0/2.0/4.0/9.0 00/01/02/03/04 09
EQ M Gain -12 - +5 - +12 34 - 4C 0A
EQ H Gain -12 - +12 34 - 4C 0B
CF Sel Chorus/Flangr 00/01 0C
CF Rate 0.05 - 0.45 - 6.40 *7 0D
CF Depth 0 - 40 - 127 00 - 7F 0E
CF Fb -98% - +30% - +98% 0F - 71 0F
+ CF Mix 0 - 100 - 127 00 - 7F 10
Dly Time 0m - 120m - 635m *5 11
Dly Fb 0 - 40 - 127 00 - 7F 12
Dly HF 315 - 8k/Bypass *8 13
# Dly Mix 0 - 30 - 127 00 - 7F 14
Level 0 - 95 - 127 00 - 7F 16
+: Effect control 1 can be used to modify the value (p.92)
#: Effect control 2 can be used to modify the value (p.92)
MSB/LSB: Indicates the ** portion of the following exclusive
messages. (p.196) (hexadecimal notation)
For Effect Type (data section)
F0 41 dev 42 12 40 03 00 ** ** sum F7
For Effect Parameters (LSB part of address)
F0 41 dev 42 12 40 03 ** data sum F7
(dev: device ID, sum: checksum)
The correspondence between setting values and hexadeci-
mal values for items in the Value column indicated with "*" is
shown in the "Effect Data Table" (p. 183).
*1 Pre Delay Time *8 HF Damp
*2 Delay Time 1 *9 Cutoff Freq
*3 Delay Time 2 *10 EQ Freq
*4 Delay Time 3 *11 LPF
*5 Delay Time 4 *12 Manual
*6 Rate 1 *13 Azimuth
*7 Rate 2 *14 Accl
